BD6225FP-E2 Rohm Semiconductor – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Output Configuration Half Bridge (4)
Applications DC Motors, General Purpose
Interface Logic
Load Type Inductive
Technology Power MOSFET
Rds On (Typ) 1.5Ohm
Current - Output / Channel 500mA
Voltage - Supply 6V ~ 15V
Voltage - Load 6V ~ 15V
Temperature Range - Operating -40°C ~ 85°C (TA)
Fault Protection Current Limiting, Over Temperature, Over Voltage, UVLO
Mounting Type Surface Mount
Case / Package 25-SOP (0.213", 5.40mm Width) + 2 Heat Tabs
Supplier Device Package 25-HSOP
Package Tape & Reel
Supply and Demand Status Shortage
Win Source Part Number 1504502-BD6225FP-E2
Ultra Librarian 3D Model Ultra Librarian BD6225FP-E2 CAD Model
