Products specifications

Category Integrated Circuits (ICs) - Power Management (PMIC) - Motor Drivers, Controllers
Mfr Rohm Semiconductor
Series -
Package Tape & Reel
Product Status Active
Motor Type - Stepper -
Motor Type - AC, DC Brushless DC (BLDC)
Function Controller - Commutation, Direction Management
Output Configuration Pre-Driver - Half Bridge (3)
Interface Logic
Technology DMOS
Step Resolution -
Applications Fan Motor Driver
Current - Output 1A
Voltage - Supply 5V ~ 16V
Voltage - Load -
Temperature Range - Operating -40°C ~ 100°C
Mounting Type Surface Mount
Package / Case 16-VSSOP (0.173", 4.40mm Width) Exposed Pad
Supplier Device Package 16-HTSSOP-B
Base Product Number BD63242
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1354618-BD63242EFV-E2
Ultra Librarian 3D Model Ultra Librarian BD63242EFV-E2 CAD Model

Description

The BD63242EFV-E2 is an integrated circuit from Rohm Semiconductor.

  • Type: Motor Driver Controller
  • Application: Fan Motor
  • Voltage Supply: 5V to 16V
  • Current Output: 1A
  • Output Configuration: Pre-Driver - Half Bridge (3)
  • Package: 16-VSSOP with Exposed Pad
  • Mounting Type: Surface Mount
  • Series: BD63242
  • Packaging: Tape and Reel
  • Technology: DMOS
  • ECCN: EAR99
  • Function: Commutation and Direction Management
  • Motor Type: Brushless DC (BLDC)
  • Operating Temperature: -40°C to 100°C
  • REACH: Unaffected
