Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Rohm Semiconductor
Packaging Reel - TR
Status Active
Type DC DC Regulator
Topology Step-Up (Boost)
Internal Switch(s) Yes
Number of Outputs 2
Operating Input Voltage(Min) 2.7V
Maximum Supply Voltage 5.5V
Output Voltage 28.5V
Channel Output Current 25mA
Frequency 600kHz to 1.1MHz
Dimming PWM
Applications Backlight
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 12-UCSP50L1 (1.4x1.8)
Win Source Part Number 1023033-BD65B60GWL-E2
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian BD65B60GWL-E2 CAD Model

Description

The BD65B60GWL-E2 is a PMIC (Power Management Integrated Circuit) specifically designed as an LED driver by Rohm Semiconductor. This IC is optimized for driving LEDs efficiently and reliably in various lighting applications. It provides features such as constant current control, overvoltage protection, and thermal shutdown to ensure optimal performance and longevity of the LED lighting system.

Applications

  • LED Backlighting for LCD Displays
  • General Lighting Applications
  • Automotive Lighting
  • Mobile Device Backlighting
  • Industrial Lighting

Features

  • Constant Current Control: Ensures consistent brightness and prevents LED damage.
  • Overvoltage Protection: Protects the LEDs from damage due to voltage spikes.
  • Thermal Shutdown: Prevents overheating and ensures reliable operation.
  • High Efficiency: Minimizes power consumption and maximizes LED brightness.
  • Compact Package: Facilitates easy integration into space-constrained applications.

Benefits

  • Improved LED Lifespan: Extends the operational life of LEDs by providing stable and protected power.
  • Enhanced Energy Efficiency: Reduces power consumption, leading to lower operating costs.
  • Increased System Reliability: Ensures consistent and reliable LED performance.
  • Simplified Design: Reduces the number of external components required, streamlining the design process.
  • Compact Solution: Enables smaller and more compact lighting systems.

Additional Details

The BD65B60GWL-E2 operates within a specified voltage range and temperature, ensuring robust performance under diverse conditions. Its constant current control feature allows for precise adjustment of LED brightness. The overvoltage protection and thermal shutdown features safeguard the LEDs from potential damage, enhancing the reliability of the lighting system.

Rohm Semiconductor's advanced manufacturing techniques guarantee high reliability and consistent quality. The compact package size makes it suitable for integration into portable and space-sensitive applications. The BD65B60GWL-E2 is a versatile and efficient LED driver solution for a wide range of lighting applications.
