Products specifications Report Issue?

Category Capacitors>Aluminum Electrolytic Capacitors
Mfr Rubycon
Series YXJ
Package Bulk
Capacitance 1000 µF
Tolerance ±20%
Voltage - Rated 63 V
Lifetime @ Temp. 10000 Hrs @ 105°C
Temperature Range - Operating -40°C ~ 105°C
Polarization Polar
Applications General Purpose
Ripple Current @ Low Frequency 1.147 A @ 120 Hz
Ripple Current @ High Frequency 2.73 A @ 100 kHz
Impedance 32 mOhms
Lead Spacing 0.295" (7.50mm)
Dimension 0.630" Dia (16.00mm)
Height - Seated (Max) 1.063" (27.00mm)
Mounting Type Through Hole
Package / Case Radial, Can
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.22.0020
Other Names 63YXJ1000M16X25-ND,1189-4229
Standard Package 600
Win Source Part Number 983727-63YXJ1000M16X25
Ultra Librarian 3D Model Ultra Librarian 63YXJ1000M16X25 CAD Model

Description

The YXJ series aluminum electrolytic capacitor from Rubycon is a high-quality capacitor designed for general-purpose applications.

  • Capacitance: 1000 µF
  • Voltage Rating: 63 V
  • Series: YXJ
  • Tolerance: ±20%
  • Impedance: 32 mOhms
  • Lifetime: 10000 Hours @ 105°C
  • Polarized: Yes
  • Mounting Type: Through-Hole
  • Package/Case: Radial, Can
  • Diameter: 0.630 inches (16.00mm)
  • Height: 1.063 inches (27.00mm)
  • Packaging: Bulk
  • Standard Package: 600
