The Tiger Eye™ SFMC series SFMC-137 is a 74 position receptacle connector with a push-pull fastening type.

• Style: board-to-board or cable style.
• Pitch-Mating: 0.050" (1.27mm).
• Row Spacing-Mating: 0.050" (1.27mm).
• Contact Type: female socket.
• Positions Loaded: all the positions.
• Contact Material: beryllium copper.
• Contact Finish-Mating: gold with a thickness of 30.0µin (0.76µm).
• Contact Finish-Post: tin.
• Insulation Material: liquid crystal polymer (LCP).
• Insulation Height: 0.185" (4.70mm).
• Insulation Color: black.
• Current Rating: 2.9A per contact.
• Temperature Range: -55°C ~ 125°C.
• Material Flammability Rating: UL94 V-0.
• Standard Package: 1.
• Ideal for: use in applications that require a high-speed board-to-board or cable connection.
