Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Isolators - Optoisolators - Logic Output Optoisolators
Mfr Sharp Microelectronics
Series OPIC™
Package Tape & Reel (TR)Cut Tape (CT)
Product Status Obsolete
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Voltage - Isolation 3750Vrms
Input Type DC
Output Type Open Collector
Current - Output / Channel 50 mA
Propagation Delay tpLH / tpHL (Max) 6µs, 3µs
Rise / Fall Time (Typ) 100ns, 50ns
Voltage - Forward (Vf) (Typ) 1.1V
Current - DC Forward (If) (Max) 50mA
Voltage - Supply 3V ~ 15V
Temperature Range - Operating -25°C ~ 85°C
Mounting Type Surface Mount
Package / Case 6-SOIC (0.173", 4.40mm Width), 5 Leads
Supplier Device Package 5-MFP
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.49.8000
Win Source Part Number 653050-PC400
Ultra Librarian 3D Model Ultra Librarian PC400 CAD Model

Description

The 653050-PC400 is a logic output optoisolator from Sharp Microelectronics.

  • Application: isolating low voltage control circuits from high voltage power circuits
  • Package Options: tape & reel or cut tape
  • Maximum Forward Current: 50mA
  • Typical Forward Voltage: 1.1V
  • Rise/Fall Time: 100ns/50ns
  • Output Current: 50mA
  • Channel: single
  • Voltage Isolation: 3750Vrms
  • Output Type: open collector
  • Input: DC
  • Voltage Supply Range: 3V to 15V
  • Operating Temperature: -25°C to 85°C
  • Status: obsolete
