Products specifications

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Tube/Rail
Status Active
Transistor Polarity PNP - Darlington
Maximum Current Collector 12A
VCEO Maximum Collector-Emitter Breakdown Voltage 100V
Max Vce (sat) 3V @ 100mA, 10A
Collector Cut-off Current(Max) 1mA
Typical Gain (hFE) (Min) 750 @ 5A, 3V
Maximum Power Dissipation 80W
Temperature Range - Operating 150°C (TJ)
Mounting Through Hole
Case / Package TO-220AB
Win Source Part Number 038586-BDW94C
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Audio, Motor Drive & Control, Industrial, Power Management
Ultra Librarian 3D Model Ultra Librarian BDW94C CAD Model

Description

The BDW94C is a high-power PNP transistor manufactured by STMicroelectronics, a global semiconductor leader known for its commitment to delivering products that enable smarter driving and smarter factories, cities, and homes, along with the next generation of mobile and Internet of Things solutions.

Key Features

  • PNP Polarity: The BDW94C is a PNP transistor, which means it is designed to pass current predominantly from the emitter to collector when a positive voltage is applied to the base terminal.
  • High Power Dissipation: With a power dissipation of up to 90W, this transistor can handle significant energy without overheating, making it suitable for high-power applications.
  • Collector-Emitter Voltage: It offers a collector-emitter voltage (VCEO) of up to -100V, providing a wide range of operational capabilities for various circuit designs.
  • Collector Current: The BDW94C can manage a continuous collector current (IC) of up to -12A, allowing for substantial current flow through the device.
  • Complementary NPN Type: It has a complementary NPN type BDW93C, enabling use in push-pull and other balanced amplifier designs.

Applications

The BDW94C is ideal for a variety of applications that require high power and efficiency. It is commonly used in:

  • Linear and switching industrial equipment
  • Power amplifiers
  • Regulators
  • Relay drivers

Quality and Reliability

STMicroelectronics ensures the BDW94C meets rigorous quality and reliability standards. The device is constructed with state-of-the-art manufacturing processes and is designed to withstand challenging conditions while maintaining performance.

Environmental Compliance

The BDW94C is compliant with RoHS (Restriction of Hazardous Substances) and is lead-free, reflecting STMicroelectronics' commitment to environmental sustainability and reducing the ecological impact of its products.
