Products specifications

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr STMicroelectronics
Series BZW50, TRANSIL™
Package Cut Tape (CT)Tape & Box (TB)
Product Status Active
Type Zener
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 18V
Voltage - Breakdown (Min) 20V
Voltage - Clamping (Max) @ Ipp 41.5V
Current - Peak Pulse (10/1000µs) 1446A (1.446kA) (8/20µs)
Power - Peak Pulse 5000W (5kW)
Power Line Protection No
Applications General Purpose
Capacitance @ Frequency 11500pF @ 1MHz
Mounting Type Through Hole
Package / Case R-6, Axial
Supplier Device Package R-6
Base Product Number BZW50
Standard Package 100 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 574923-BZW50-18
Ultra Librarian 3D Model Ultra Librarian BZW50-18 CAD Model

Description

The BZW50-18 is a robust Transil diode from the industry-leading semiconductor manufacturer, STMicroelectronics. This high-power transient voltage suppressor (TVS) is designed to provide reliable protection for sensitive electronic equipment against voltage transients induced by system inductive load switching and lightning disturbances.

Key Features

  • Stand-off Voltage: The BZW50-18 is equipped with a stand-off voltage of 18V, making it suitable for a range of applications that require voltage regulation and protection.
  • Peak Pulse Power: It can handle a peak pulse power dissipation of 5000W (10/1000μs surge), ensuring effective protection against high energy transients.
  • Fast Response Time: With its fast response time, this diode reacts quickly to surge events, minimizing the risk of damage to the protected components.
  • Low Clamping Voltage: The low clamping voltage of the BZW50-18 helps to safeguard sensitive circuits by reducing the stress caused by transient overvoltages.
  • High Surge Capability: Its high surge capability makes it ideal for absorbing potentially damaging spikes in electrical circuits.

Applications

The BZW50-18 is versatile and can be used in a variety of applications, including:

  • Power supply protection
  • AC/DC applications
  • Telecommunication systems
  • Industrial electronics
  • Lightning surge protection

Quality and Reliability

STMicroelectronics is committed to delivering high-quality products. The BZW50-18 Transil diode is manufactured with rigorous standards to ensure it meets the reliability and performance requirements of the most demanding applications. It is RoHS compliant and adheres to international safety standards, providing peace of mind for engineers and product developers integrating this component into their designs.

Package Information

The BZW50-18 comes in a molded plastic case and is characterized by its axial leads which are intended for through-hole mounting. This package allows for easy installation and is designed to optimize thermal and electrical performance.
