Products specifications

Categories Circuit Protection
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type Zener
Bidirectional Channels 4
STAND-OFF Voltage (Vwm) 5V
Minimum Breakdown Voltage 6.1V
Power Dissipation - Pd 80W
Applications General Purpose
Temperature Range - Operating -40°C to 125°C (TA)
Mounting SMD (SMT)
Case / Package SOT-23-6
Win Source Part Number 015714-ESDA6V1BC6
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ESDA6V1BC6 CAD Model

Description

STMicroelectronics ESDA6V1BC6 - ESD Protection Device

The ESDA6V1BC6 is a state-of-the-art ESD protection device manufactured by STMicroelectronics, a leader in the semiconductor industry. This compact and efficient solution is designed to safeguard high-speed data lines and other vulnerable circuits from the damaging effects of Electrostatic Discharge (ESD), which can occur during manufacturing, handling, or in the field.

Key Features

  • Transient Protection: The ESDA6V1BC6 is capable of withstanding ESD discharges up to 15 kV (air discharge) and 8 kV (contact discharge) as per the IEC 61000-4-2 standard, providing robust protection for sensitive components.
  • Low Capacitance: With a very low capacitance of typically 10 pF, this device is particularly suitable for protecting high-speed data lines without compromising signal integrity.
  • Low Leakage Current: It features a very low leakage current, ensuring minimal power consumption when the device is in standby mode, making it suitable for power-sensitive applications.
  • Multi-line Protection: The ESDA6V1BC6 is designed to protect up to 6 lines, making it a versatile solution for a wide range of applications.
  • Small Package: The device comes in an SOT-23-6L package, which is ideal for space-constrained applications.

Applications

The ESDA6V1BC6 is widely used in various industries due to its ability to protect multiple lines in a single package. It is particularly suitable for:

  • USB 2.0, USB 3.0, and HDMI interfaces
  • High-speed data lines in mobile phones, tablets, and other portable devices
  • Networking and telecommunications equipment
  • Consumer electronics such as digital cameras, MP3 players, and TVs

Reliability and Performance

STMicroelectronics ensures the reliability and performance of the ESDA6V1BC6 by adhering to rigorous industry standards. The device's ability to protect against ESD events while maintaining signal integrity makes it an essential component in the design of electronic systems that require high levels of protection against transient voltage spikes.

Overall, the ESDA6V1BC6 from STMicroelectronics is an excellent choice for engineers looking to enhance the ESD robustness of their designs with a reliable, high-performance solution.
