Products specifications

Categories Circuit Protection
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type Steering (Rail to Rail)
Unidirectional Channels 4
STAND-OFF Voltage (Vwm) 3V
Minimum Breakdown Voltage 6V
Power Dissipation - Pd 90W
Power Line Protection Yes
Applications General Purpose
Capacitance @ Frequency 2.5pF @ 1MHz
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-666
Win Source Part Number 1037143-ESDALCL6-4P6A
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ESDALCL6-4P6A CAD Model

Description

Introducing the ESDALCL6-4P6A from STMicroelectronics

The ESDALCL6-4P6A is a state-of-the-art transient voltage suppressor designed by STMicroelectronics, specifically crafted to protect sensitive electronic equipment from electrostatic discharges (ESD) as well as other transient voltage events. This robust component is an ideal choice for safeguarding high-speed data lines and other vulnerable circuits used in a wide array of applications including mobile devices, computers, and consumer electronics.

Key Features

  • Low Clamping Voltage: The device offers a very low clamping voltage, ensuring that sensitive components are well protected from voltage spikes.
  • High ESD Protection: It can withstand ESD up to 15 kV (air discharge) and 8 kV (contact discharge) as per the IEC 61000-4-2 standard, providing a high level of protection for electronic devices.
  • Low Leakage Current: With a very low leakage current, the ESDALCL6-4P6A does not significantly affect the normal operation of the circuit it is protecting.
  • Multi-Line Protection: This device can protect up to four data or power lines simultaneously, making it a versatile solution for various applications.
  • Fast Response Time: Its response time to ESD events is extremely quick, ensuring that the protected components are immediately shielded from harmful voltage transients.
  • Small Package Size: The ESDALCL6-4P6A comes in a small SOT-666 package, making it suitable for high-density circuit boards where space is at a premium.

Applications

The ESDALCL6-4P6A is designed for applications that require robust ESD protection without compromising signal integrity. It is commonly used in:

  • USB interfaces
  • HDMI ports
  • Serial and parallel ports
  • Mobile phones and other portable devices
  • Set-top boxes and digital TVs
  • Notebook and desktop computers

STMicroelectronics' commitment to quality and reliability is reflected in the ESDALCL6-4P6A, providing designers with a dependable solution to protect their electronic systems from the damaging effects of ESD and other transient voltage events. By integrating this component into your design, you can enhance the durability and longevity of your electronic products, ensuring customer satisfaction and reducing the risk of warranty claims due to ESD damage.
