Products specifications

Categories Development Boards, Kits, Programmers
Manufacturer STMicroelectronics
Series VIPower
Main Purpose Power Management, High Side Driver (Internal FET)
Utilized IC / Part VND5E050K
Primary Attributes 2-Channel (Dual)
Supplied Contents Board(s)
Win Source Part Number 799141-EV-VND5E050K
Popularity Medium
Supply and Demand Status Balance
Family Name VND5E050K
ECCN EAR99
Estimated EOL Date 2030
Ultra Librarian 3D Model Ultra Librarian EV-VND5E050K CAD Model

Description

STMicroelectronics EV-VND5E050K Evaluation Board

The EV-VND5E050K from STMicroelectronics is a state-of-the-art evaluation board designed for automotive applications, specifically tailored for the testing and evaluation of the VND5E050K double channel high-side driver. This evaluation board is an essential tool for engineers and developers seeking to test the capabilities of the VND5E050K chip in a controlled and efficient manner.

Key Features

  • High-Side Driver Integration: The VND5E050K is a sophisticated double channel high-side driver integrated into the board, which is designed to drive automotive loads with excellent power efficiency.
  • Advanced Protection Systems: The evaluation board includes features such as overcurrent, overvoltage, and thermal shutdown protection to ensure the longevity and reliability of the application under test.
  • Diagnostic Functions: Built-in diagnostic functions allow for real-time monitoring, which is crucial for the development and troubleshooting of automotive applications.
  • User-Friendly Interface: The EV-VND5E050K board comes with a user-friendly interface that includes accessible pins and connectors, making it easy to set up and use.
  • Versatility: It is designed to handle a wide range of automotive load types, making it a versatile tool for various testing scenarios.

Applications

The evaluation board is suitable for a myriad of automotive applications, including but not limited to:

  • Automotive lighting systems
  • Engine control units
  • Body control modules
  • Other automotive power management systems

Technical Specifications

The EV-VND5E050K evaluation board is designed to accommodate the technical requirements of modern automotive systems. It supports a wide supply voltage range and is capable of driving significant current levels. The board's layout is optimized for heat dissipation, ensuring performance is maintained even under high load conditions.

Conclusion

STMicroelectronics' EV-VND5E050K evaluation board is an indispensable tool for professionals in the automotive industry. Its robust design, comprehensive protection features, and diagnostic capabilities provide a reliable platform for developing and testing applications that require high-side driving solutions.
