Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Obsolete(EOL)
Logic Type NAND Gate
Number of Circuits 4
Number of Inputs 2
Features Schmitt Trigger
Supply Voltage - Operating 3 V to 20 V
Current - Quiescent (Max) 20μA
Current - Output High, Low 6.8mA, 6.8mA
Logic Level - Low 0.9 V to 4 V
Logic Level - High 3.6 V to 10.8 V
Max Propagation Delay @ V, Max CL 130ns @ 15V, 50pF
Temperature Range - Operating -55°C to 125°C
Mounting SMD (SMT)
Case / Package 14-SO
Dimension 14-SOIC (0.154", 3.90mm Width)
Win Source Part Number 117809-HCF4093M013TR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name HCF4093
Introduction Date August 15, 1995
ECCN EAR99
Country of Origin China, Italy, Malta, Morocco
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian HCF4093M013TR CAD Model

Description

The HCF4093M013TR is a robust, high-performance quadruple 2-input NAND Schmitt trigger integrated circuit (IC) produced by STMicroelectronics. This IC is designed to operate with a wide supply voltage range, from 3V to 15V, making it suitable for a variety of applications in both consumer and industrial electronics. The device comes in a compact surface-mount SO-14 package, which is ideal for space-constrained applications.

Key Features

  • Logic Type: The HCF4093M013TR consists of four independent NAND Schmitt triggers, providing versatile functionality for building complex logic circuits.
  • Supply Voltage Range: This device can operate over a wide range of supply voltages, from 3V to 15V, allowing it to be used in various power environments.
  • Hysteresis Characteristics: The Schmitt trigger inputs feature hysteresis, which enhances noise immunity and transforms slowly changing input signals into sharply defined jitter-free output signals.
  • Output Drive Capability: The IC has the ability to drive TTL and CMOS outputs, which makes it compatible with a wide range of digital circuits.
  • Package Type: Packaged in a SO-14 format, the HCF4093M013TR is designed for surface mounting, which saves precious board space and is suitable for automated assembly processes.
  • Temperature Range: The device is operational over a temperature range of -55°C to +125°C, ensuring reliability and performance under extreme conditions.

Applications

The versatility of the HCF4093M013TR allows it to be used in a broad array of applications, including:

  • Wave and pulse shapers
  • High noise environment logic circuits
  • Astable multivibrators
  • Monostable multivibrators
  • Signal processing
  • Complex logic circuit implementation

With its reliable performance and STMicroelectronics' commitment to quality, the HCF4093M013TR is an excellent choice for designers looking to incorporate a NAND Schmitt trigger into their digital logic systems.
