Products specifications Report Issue?

Categories Circuit Protection
Manufacturer STMicroelectronics
Series HSP
Packaging Reel package
Type Steering (Rail to Rail)
Unidirectional Channels 2
Voltage - Reverse Standoff (Typ) 3V
Minimum Breakdown Voltage 6V
Maximum Clamping Voltage 18V (Typ)
Current - Peak Pulse (10/1000μs) 3A (8/20μs)
Power Line Protection Yes
Applications Ethernet, HDMI
Capacitance @ Frequency 0.6pF @ 200MHz ~ 3GHz
Operating Temperature Range -40°C ~ 150°C (TJ)
Mounting SMD
Package 6-UFDFN
Manufacturer Package 6-uQFN (1.45x1)
Win Source Part Number 776236-HSP062-2M6
Popularity Medium
Supply and Demand Status Limited
Family Name HSP062-2M6
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian HSP062-2M6 CAD Model

Description

STMicroelectronics HSP062-2M6 - ESD Protection Device

The HSP062-2M6 is a robust ESD protection device designed by STMicroelectronics, a global semiconductor leader. This component is specifically engineered to safeguard high-speed data lines from electrostatic discharge (ESD) threats, which are common during electronic equipment handling and can cause irreversible damage to sensitive circuitry.

Key Features

  • High ESD Protection: The HSP062-2M6 offers a superior ESD protection level of up to 2 kV (kilovolts), compliant with the IEC61000-4-2 international standard.
  • Low Capacitance: With a low line capacitance, this device ensures signal integrity is maintained, making it ideal for protecting high-speed data lines without compromising data transfer rates.
  • High Integration: The device integrates six channels of ESD protection, which allows for a reduction in PCB (printed circuit board) space and simplifies the design process for multi-line applications.
  • Flow-Through Design: The HSP062-2M6's flow-through design ensures easy PCB layout and matched trace lengths, which is critical for maintaining signal integrity in high-speed applications.
  • Bidirectional Protection: This device provides bidirectional ESD protection, which means it can protect electronic circuits regardless of the direction from which the ESD event occurs.

Applications

The HSP062-2M6 is versatile and can be used in a variety of applications, including:

  • USB 2.0 and 3.0 interfaces
  • HDMI and DisplayPort interfaces
  • Digital Visual Interface (DVI) applications
  • Thunderbolt interfaces
  • Other high-speed data lines requiring ESD protection

Why Choose the HSP062-2M6?

STMicroelectronics' HSP062-2M6 stands out for its high level of protection, low capacitance, and multi-channel integration. It is a preferred choice for designers looking to enhance the reliability and longevity of their high-speed data interfaces. By selecting the HSP062-2M6, you are choosing a product that combines performance with practicality, ensuring your electronic devices are shielded from the potentially damaging effects of ESD.
