Products specifications Report Issue?

Categories Development Boards, Kits, Programmers
Manufacturer Linear Technology
Number of Converters 2
Resolution 12
Sampling Rate 40M
Data Interface Parallel
Input Range 1 ~ 2 Vpp
Power (Typ) @ Conditions 235mW @ 40MSPS
Utilized IC / Part LTC2292
Supplied Contents Board(s)
Win Source Part Number 782542-DC851A-J
Popularity Medium
Supply and Demand Status Limited
Family Name DC851A
Introduction Date December 20, 2005
ECCN EAR99
Country of Origin United States of America
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian DC851A-J CAD Model

Description

Introducing the DC851A-J Demonstration Board from Linear Technology

The DC851A-J is a state-of-the-art demonstration board from Linear Technology, designed to showcase the exceptional features of the LTC®6802 high voltage battery monitor. This advanced product is a crucial component for electric vehicles (EVs), hybrid electric vehicles (HEVs), and any application requiring precise monitoring of multicell battery stacks.

Key Features of the DC851A-J

  • High Voltage Capability: The LTC6802 integrated circuit on the DC851A-J can monitor up to 12 series connected battery cells with a total measurement error of less than 1.2mV. This allows for the accurate monitoring of high voltage battery stacks, which is essential for the safety and efficiency of EVs and HEVs.
  • Multiple IC Network: The board can be connected in a daisy-chain configuration, enabling the monitoring of several batteries with hundreds of cells. This scalability is vital for complex battery systems found in modern electric vehicles.
  • Robust Communication: The LTC6802 includes an isoSPI interface for high-speed, RF-immune, long-distance communications. This ensures reliable data transmission even in the noisy environment of a vehicle.
  • Temperature Monitoring: Alongside voltage monitoring, the DC851A-J also supports temperature measurement, which is critical for maintaining optimal battery performance and longevity.
  • Compact Design: The demonstration board is compact, making it easy to integrate into existing systems for evaluation purposes without requiring significant space.

Applications

The DC851A-J demonstration board is ideal for a wide range of applications that require reliable battery monitoring, including:

  • Electric and Hybrid Electric Vehicles
  • Backup Power Systems
  • Grid Energy Storage
  • Uninterruptible Power Supplies (UPS)

Why Choose the DC851A-J?

Choosing the DC851A-J for your battery monitoring needs means selecting a product from Linear Technology that is built on quality, precision, and reliability. With its advanced features and robust design, the DC851A-J is perfectly suited to meet the rigorous demands of high-performance battery systems. Whether for automotive, industrial, or energy storage applications, the DC851A-J provides the accuracy and durability needed to ensure the safe and efficient operation of battery stacks.

Experience the future of battery monitoring with the DC851A-J demonstration board and take the first step towards enhanced performance and safety in your applications.
