The L200CV from STMicroelectronics is a versatile and robust adjustable voltage and current regulator, designed to offer a flexible solution for a wide range of power supply and charger applications. This regulator is capable of delivering up to 2A of output current with an output voltage that can be set from 2.85V to 36V, providing designers with a high degree of control over their power management requirements.
Key Features
- Adjustable Output: Both voltage and current levels can be adjusted through external resistors, making the L200CV incredibly versatile for various applications.
- High Output Current: Capable of delivering up to 2A, this regulator can power a wide range of devices and circuits.
- Overload Protection: The L200CV includes thermal shutdown and current limiting features, ensuring the safety and longevity of both the regulator and the connected components.
- Short Circuit Protection: The device is protected against short circuits, which may occur during operation, adding an extra layer of reliability.
- Input Voltage Range: The device operates with an input voltage range from 2.85V up to 40V, providing flexibility in the choice of power sources.
Applications
The L200CV is suited for a broad spectrum of applications, including:
- Adjustable power supplies
- Battery chargers
- Motor control
- Current limiting circuits
Product Specifications
Parameter
Value
Output Current (max)
2A
Output Voltage Range
2.85V to 36V
Input Voltage Range
2.85V to 40V
Thermal Overload Protection
Yes
Short Circuit Protection
Yes
Package
Pentawatt (Vertical)
With its high level of integration and protection features, the L200CV from STMicroelectronics is an excellent choice for engineers and designers looking for a reliable and adjustable power solution.
