Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer STMicroelectronics
Packaging Reel - TR
Output Configuration Half Bridge (4)
Applications DC Motors, Relays, Solenoids, Stepper Motors
Interface Logic
Load Type Inductive
Technology Bipolar
Current - Peak Output 2A
Operating Supply Voltage 4.5 V ~ 7 V
Voltage - Load 4.8 V ~ 46 V
Operating Temperature Range -40°C ~ 150°C (TJ)
Fault Protection Current Limiting, Over Temperature
Mounting SMD
Package 20-SOIC (0.433", 11.00mm Width) Exposed Pad
Manufacturer Package PowerSO-20
Manufacturer Homepage www.st.com
Win Source Part Number 710683-L298P013TR
Family Name L298
Introduction Date February 05, 1998
ECCN EAR99
Country of Origin United States of America
Halogen Free Compliant
Estimated EOL Date 2025
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian L298P013TR CAD Model

Description

The L298P013TR from STMicroelectronics is a powerful dual full-bridge driver designed to accept standard TTL logic levels and drive inductive loads such as relays, solenoids, DC and stepping motors. It's an integrated monolithic circuit housed in a 15-lead Multiwatt package. The device is designed to provide bidirectional drive currents of up to 2A at voltages from 4.8 V to 46 V.

Key Features

  • Operating Voltage Range: The L298P013TR operates efficiently across a wide range of voltages, from 4.8 V to 46 V, making it versatile for various applications.
  • High Current Output: It can handle peak currents of up to 2A per channel or 4A max for the entire package, with the capability to withstand surge currents up to 3A.
  • Low Saturation Voltage: The device features low saturation voltage, reducing power dissipation and improving efficiency.
  • Overtemperature Protection: It includes intrinsic overtemperature protection, ensuring the device remains safe under extreme operating conditions.
  • Logical "0" Input Voltage up to 1.5 V: The driver accepts TTL logic signals, with logical "0" input voltage up to 1.5 V (high-noise immunity).

Applications

The versatility of the L298P013TR makes it suitable for a wide array of applications, including:

  • Stepper Motor Controllers
  • DC Motor Drivers
  • Robotics and Automation Systems
  • Position and Velocity Servomechanisms
  • Factory Automation Equipment

Product Details

The L298P013TR is available in a 15-pin Multiwatt package, ensuring robustness and ease of mounting on a printed circuit board. The package also provides heat sinking to manage thermal performance. Its design is optimized for simplified circuitry with fewer external components, making it a go-to solution for driving motors in a compact and efficient manner.

With the L298P013TR, STMicroelectronics continues to deliver high-quality, reliable solutions for the control of inductive loads in embedded systems. Whether for educational projects, hobbyist applications, or industrial machinery, this motor driver stands out for its performance and durability.
