Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Applications Resonant Converter Controller
Supply Voltage - Operating 8.85 V to 16 V
Operating Supply Current 3.5mA
Temperature Range - Operating 0°C to 105°C
Mounting SMD (SMT)
Case / Package 16-SO
Win Source Part Number 018302-L6599DTR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name L6599
Introduction Date May 15, 2006
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian L6599DTR CAD Model

Description

The L6599DTR, manufactured by STMicroelectronics, is a state-of-the-art resonant controller specifically designed for high-efficiency resonant power supplies. This advanced controller is an integral component for applications requiring reliable and efficient power conversion, making it an ideal choice for designers looking to enhance their power supply solutions.

Key Features

  • High-Voltage Capability: The L6599DTR is capable of handling high-voltage operations, which is crucial for applications that require a wide input voltage range.
  • Integrated Bootstrap Diode: This feature simplifies the circuit design by reducing the number of external components needed, thereby saving space and cost.
  • Frequency Modulation: The device offers frequency modulation for spread spectrum, which helps in reducing electromagnetic interference (EMI), making it suitable for applications sensitive to noise.
  • Soft-Start and Shutdown Control: The soft-start capability ensures a gradual increase in power, thereby preventing abrupt changes that could damage the system. The shutdown control provides a safe and orderly power-down sequence.

Applications

The L6599DTR is versatile and can be used in a variety of applications, including:

  • Flat-panel television power supplies
  • High-efficiency AC-DC adapters
  • Power supplies for servers and telecommunication systems
  • LED lighting systems

Technical Specifications

With an operating frequency up to 500kHz, the L6599DTR allows for smaller-sized components, which contributes to a reduction in overall design size. The device also features an adjustable dead-time, enabling optimization for efficiency and EMI performance across different load conditions.

Quality and Reliability

STMicroelectronics is known for its commitment to quality and reliability, and the L6599DTR is no exception. It is designed to meet the rigorous standards required for industrial and consumer applications, ensuring a long operational life and consistent performance.

Environmental Considerations

The L6599DTR is compliant with RoHS and is designed with the aim of minimizing its environmental impact. It supports energy-efficient operation, which can contribute to reduced energy consumption in end-user applications.
