Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Switch Type General Purpose
Number of Outputs 8
Output Type N-Channel
Voltage - Load 4.5 V to 18 V
Supply Voltage - Operating 4.5 V to 5.5 V
Current - Output (Max) 1A
Rds On (Typ) 700 mOhm (Max)
Input Type Non-Inverting
Features PWM Input
Fault Protection Open Load Detect, Over Temperature
Temperature Range - Operating -40°C to 125°C (TA)
Case / Package PowerSSO-28
Win Source Part Number 1051423-L9733CNTR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian L9733CNTR CAD Model

Description

Product Overview: L9733CNTR from STMicroelectronics

The L9733CNTR is a versatile and robust integrated circuit designed by STMicroelectronics, a global leader in semiconductor solutions. This high-performance product is part of the Power Management ICs category and is particularly suited for automotive applications. It is designed to manage and control various solenoids, relays, and other actuators with precision and efficiency.

Key Features

  • Output Current Control: The L9733CNTR can drive up to 8 outputs with a current control to minimize power dissipation.
  • Voltage Range: It operates over a wide supply voltage range, which is suitable for automotive environments that require a robust performance under varying conditions.
  • Diagnostic Functions: Equipped with built-in diagnostic capabilities, it can detect open-load, overtemperature, and short-circuit conditions, providing crucial feedback for system monitoring and safety.
  • Serial Interface: The device includes a serial peripheral interface (SPI) that allows digital communication with microcontrollers, making it easy to integrate into complex automotive systems.
  • Protection Features: It offers multiple protection features, including overcurrent protection and thermal shutdown, ensuring the longevity and reliability of the application it is used in.

Applications

The L9733CNTR is ideal for a variety of automotive applications, including but not limited to:

  • Engine control units
  • Body control modules
  • Power distribution centers
  • LED lighting systems

Quality and Reliability

STMicroelectronics is committed to delivering high-quality products. The L9733CNTR is manufactured with the stringent quality standards required for automotive components. It is designed to withstand the harsh conditions typical of automotive environments, ensuring reliability and performance over the product's lifespan.

Environmental Compliance

The L9733CNTR is compliant with various environmental standards, including RoHS and WEEE, reflecting STMicroelectronics' dedication to environmental sustainability and the production of eco-friendly products.
