Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 15V
Nominal Output Voltage (Min/Fixed) 3.3V
Dropout Voltage-Max 1.3V @ 1A
Output Current 1A
Operating Supply Current 10mA
PSRR 75dB (120Hz)
Control Protection Features Over Current, Over Temperature
Temperature Range - Operating 0°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 3.3V
Voltage - Dropout (Typical) 1.15V @ 1A
Mounting SMD (SMT)
Case / Package SOT-223
Win Source Part Number 002405-LD1117AS33TR
Family Name LD1117A
Introduction Date June 16, 2000
ECCN EAR99
Country of Origin China
Estimated EOL Date 2022
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Power Management
Ultra Librarian 3D Model Ultra Librarian LD1117AS33TR CAD Model

Description

STMicroelectronics LD1117AS33TR Voltage Regulator

The LD1117AS33TR from STMicroelectronics is a low-dropout (LDO) voltage regulator that offers the perfect solution for robust, low-power, and stable voltage regulation. Designed to maintain accuracy and reliability, this component is ideal for a wide range of applications, including consumer electronics, computer peripherals, and embedded systems.

Key Features

  • Output Voltage: The LD1117AS33TR provides a fixed output voltage of 3.3V, which is a common requirement for digital circuits and microcontroller-based projects.
  • High Efficiency: As an LDO regulator, it operates with a very low dropout voltage, which means it can maintain output regulation with a minimal difference between the input and output voltages, leading to higher efficiency.
  • Output Current: Capable of delivering up to 800mA of continuous output current, making it suitable for a variety of power applications.
  • Thermal Overload Protection: The built-in thermal shutdown feature ensures that the device is protected from damage due to overheating.
  • Short Circuit Protection: The regulator also includes short circuit protection to safeguard your circuitry in case of a fault condition.
  • Low Ground Current: The ground current is low at the dropout condition, which helps in maintaining efficiency and prolonging battery life in portable applications.
  • Package: Provided in the SOT-223 package, it is compact and suitable for high-density circuit boards.

Applications

The versatility of the LD1117AS33TR makes it an excellent choice for a variety of applications, including:

  • Portable devices
  • Post-regulation for switching supplies
  • Battery-powered devices
  • Microcontroller power supply
  • Peripheral power supply

Conclusion

With its combination of features, the LD1117AS33TR voltage regulator from STMicroelectronics is a reliable and efficient choice for designers looking to stabilize voltage in their electronic applications. Its thermal and short circuit protection features ensure a long operational life and stable performance, while its SOT-223 package makes it easy to integrate into a wide range of electronic projects.
