The LD1117STR from STMicroelectronics is a low drop voltage regulator capable of providing up to 800mA of output current. This linear voltage regulator is designed to offer a variety of benefits, including low dropout performance, which makes it ideal for applications where voltage regulation with minimal input-to-output differential is crucial.

Constructed with the intention of supplying a stable and reliable voltage source, the LD1117STR is a versatile component that can be implemented across a broad range of electronic devices. Its ability to maintain a constant output voltage despite variations in input voltage or load conditions makes it particularly suitable for sensitive electronics where voltage stability is paramount.

Key Features:

• Low Dropout Performance: With its low dropout capability, the LD1117STR ensures efficient operation even when the input voltage is close to the output voltage, reducing power loss and improving overall efficiency.
• Output Current: The device can deliver up to 800mA, making it suitable for a wide array of applications from microcontrollers to peripheral devices.
• Adjustable and Fixed Output: It provides a range of fixed output voltages, but it can also be adjusted to any value between 1.25V to 13.7V with the use of external resistors.
• Thermal Overload Protection: The built-in thermal overload protection safeguards the device against excessive power dissipation that might otherwise lead to high temperatures and potential damage.
• Short Circuit Protection: In case of a short circuit, the LD1117STR features current limiting to prevent damage to both the regulator and the powered device.
• Wide Range of Applications: Its robust design makes it suitable for use in consumer, industrial, and computer applications, among others.

Applications:

• Portable Devices
• Post Regulation for Switching Supplies
• Battery Powered Devices
• Computer Applications
• Consumer Electronics

The LD1117STR is presented in a surface-mount package, making it easy to integrate into a variety of PCB designs. With its comprehensive protection features and stable performance, the LD1117STR from STMicroelectronics is an excellent choice for designers looking to ensure a consistent power supply in their electronic projects.
