Products specifications Report Issue?

Manufacturer STMicroelectronics
Packaging Reel
Type Zener
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 43V
Voltage - Breakdown (Min) 47.8V
Voltage - Clamping (Maximum) at Ipp 68V
Current - Peak Pulse (10/1000μs) 55A
Power Line Protection No
Applications Automotive
Temperature Range - Operating -55°C ~ 175°C
Mounting Style SMD
Manufacturer Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Supplier Device Package D2PAK
Part Number Series LDP01
Manufacturer Pack Quantity 1,000
MSL Level 3 (168 Hours)
Popularity Low
Supply and Demand Status Limited
Win Source Part Number 812638-LDP01-50AY
Ultra Librarian 3D Model Ultra Librarian LDP01-50AY CAD Model

Description

The LDP01-50AY from STMicroelectronics is a state-of-the-art protection device designed to safeguard low-speed data lines and power lines against destructive electrostatic discharges (ESD), electrical fast transients (EFT), and other voltage surges that can be detrimental to electronic equipment. This product is part of STMicroelectronics' leading-edge protection devices, which are engineered to ensure the reliability and longevity of sensitive electronic components.

Key Features

  • ESD Protection: The LDP01-50AY offers robust ESD protection exceeding IEC 61000-4-2 Level 4 standards, capable of withstanding electrostatic discharges up to 30 kV (air discharge) and 30 kV (contact discharge).
  • Surge Protection: With surge capability compliant with IEC 61000-4-5, this device can handle surge currents, ensuring that connected components remain secure during transient conditions.
  • Low Clamping Voltage: The low clamping voltage feature minimizes stress on the protected component during a surge event, thereby enhancing its overall protection efficacy.
  • Low Leakage Current: The LDP01-50AY is designed with a low leakage current that preserves energy and ensures minimal impact on the operation of the protected circuit when not in surge conditions.
  • Low Capacitance: Its low line capacitance allows for the protection of high-speed data lines without compromising signal integrity.

Applications

The versatility of the LDP01-50AY makes it suitable for a broad range of applications. It is particularly well-suited for protecting:

  • USB interfaces
  • Power supply lines
  • Sensor lines
  • Industrial buses

Package and Quality

Encased in a SOT23-6L package, the LDP01-50AY is compact and can be readily integrated into various circuit designs without requiring substantial board space. The device is RoHS compliant and characterized for operation from -40°C to 85°C, ensuring reliable performance across a wide range of temperatures and environmental conditions. With its commitment to quality, STMicroelectronics provides a robust protection solution with the LDP01-50AY, tailored for modern electronic systems that demand the highest level of safeguarding against electrical threats.
