Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Tube/Rail
Status Obsolete(EOL)
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 16V
Nominal Output Voltage (Min/Fixed) 12V
Dropout Voltage-Max 0.7V @ 500mA
Output Current 500mA
Operating Supply Current 1.5mA to 12mA
PSRR 69dB to 54dB (120Hz to 10kHz)
Control Protection Features Over Current, Over Temperature
Temperature Range - Operating -40°C to 125°C
Mounting Through Hole
Case / Package 5-PENTAWATT
Win Source Part Number 1052275-LF120ABV
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LF120ABV CAD Model

Description

The LF120ABV from STMicroelectronics is a robust and reliable low-dropout voltage regulator designed to deliver a fixed output voltage of 12V with an impressive accuracy. This high-performance component is suitable for a wide range of applications, from automotive to industrial systems, where a stable voltage supply is crucial for the operation of sensitive electronic circuits.

Key Features

  • Precision Output: The LF120ABV provides a precise 12V output, which is essential for systems that require consistent power for optimal performance.
  • Low Dropout Voltage: With its low dropout characteristic, this voltage regulator maintains regulation with a minimal difference between the input and output voltage, enhancing efficiency and reducing power loss.
  • High Current Capability: Capable of supplying up to 500mA of output current, this device can support a variety of loads, from simple to more demanding applications.
  • Thermal Protection: The built-in thermal shutdown feature ensures the device operates within safe temperature limits, protecting your circuit from potential thermal damage.
  • Short-Circuit Protection: The LF120ABV is equipped with short-circuit protection, offering additional security against circuit faults and overcurrent conditions.
  • Stable with Low ESR Capacitors: This voltage regulator is designed to work with low equivalent series resistance (ESR) capacitors, which can help reduce noise and improve the stability of the power supply.

Applications

The LF120ABV is versatile and can be implemented in various applications, including:

  • Automotive electronics
  • Industrial control systems
  • Embedded systems
  • Power management solutions
  • Consumer electronics

Product Specifications

Parameter Value Output Voltage 12V Output Current Up to 500mA Dropout Voltage Low Thermal Protection Yes Short-Circuit Protection Yes Package Type TO-220

With its combination of features, the LF120ABV voltage regulator from STMicroelectronics is an excellent choice for any application requiring a reliable and efficient power supply.
