Products specifications

Categories Circuit Protection
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type Zener
Unidirectional Channels 1
STAND-OFF Voltage (Vwm) 12V
Minimum Breakdown Voltage 16V
Max Clamping Voltage 19V
Peak Pulse Current(Ippm) 1A (8/20μs)
Power Dissipation - Pd 350W
Applications General Purpose
Capacitance @ Frequency 175pF @ 1MHz
Mounting SMD (SMT)
Case / Package 4-FlipChip (0.77x0.77)
Win Source Part Number 1052441-LFTVS18-1F3
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian LFTVS18-1F3 CAD Model

Description

STMicroelectronics LFTVS18-1F3 Transient Voltage Suppressor

The LFTVS18-1F3 from STMicroelectronics is a robust, high-performance Transient Voltage Suppressor (TVS) designed to protect sensitive electronic equipment from voltage transients induced by system inductance, lightning, and other transient voltage events. This TVS diode is specifically engineered to safeguard low-voltage circuits by clamping unwanted high-energy transients.

Key Features

  • Low Clamping Voltage: The device offers a low clamping voltage, ensuring that sensitive components are well protected from transient events without being exposed to excessive residual voltages.
  • High Surge Capability: With its ability to handle high surge currents, the LFTVS18-1F3 is capable of protecting against severe transient conditions, making it suitable for use in robust industrial and consumer applications.
  • Low Leakage Current: It features a low leakage current, minimizing power loss and ensuring energy efficiency in standby mode or during normal operation.
  • Fast Response Time: The device's fast response time ensures that it reacts quickly to transient events, providing immediate protection for downstream components.
  • Unidirectional Protection: As a unidirectional TVS diode, the LFTVS18-1F3 is optimized for protecting circuits from positive transient voltages.

Applications

The LFTVS18-1F3 is ideal for a wide range of applications where voltage transient protection is critical. These include:

  • Consumer electronics such as TVs, computers, and gaming consoles
  • Telecommunication systems and equipment
  • Industrial control systems
  • Power supply units
  • Portable devices and battery-powered applications

Product Specifications

The LFTVS18-1F3 is available in a compact DO-214AB (SMC) package, which provides a balance between board space efficiency and thermal performance. The device is rated for a stand-off voltage of 18V, making it suitable for protecting 18V bus lines and power rails. Additionally, its compliance with international standards, such as RoHS and REACH, ensures that it meets global environmental and safety requirements.

With its combination of high surge capability, fast response time, and low clamping voltage, the LFTVS18-1F3 from STMicroelectronics is an excellent choice for designers looking to enhance the reliability and longevity of their electronic products.
