Products specifications Report Issue?

Category Integrated Circuits(ICs)
Family Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Manufacturer STMicroelectronics
Packaging Reel(TR)
Amplifier Type General Purpose
Number of Circuits 4
Slew Rate 0.4 V/μs
Gain Bandwidth Product 1.3MHz
Current - Input Bias 20nA
Voltage - Input Offset 2mV
Current - Supply 1.5mA
Current - Output / Channel 20mA
Voltage - Supply, Single/Dual (±) 3 V ~ 30 V, ±1.5 V ~ 15 V
Operating Temperature Range -40°C ~ 125°C
Mounting Style SMD/SMT
Package 14-SOIC (0.154", 3.90mm Width)
Manufacturer Device Package 14-SO
Win Source Part Number 018920-LM2902DT
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian LM2902DT CAD Model

Description

LM2902DT Low-Power Quad Operational Amplifier

The LM2902DT is a versatile and robust operational amplifier (Op-Amp) designed and manufactured by STMicroelectronics. This integrated circuit is part of a family of low-power, quad operational amplifiers that are particularly well-suited for battery-powered applications, consumer electronics, and industrial equipment. The LM2902DT comes in a compact SO-14 (Small Outline Package) that is conducive for space-constrained applications.

The LM2902DT is characterized by its low power consumption and wide range of supply voltages, from 3V to 32V (or ±1.5V to ±16V in a split supply configuration), making it an excellent choice for designs that require energy efficiency and flexibility. Each of the four amplifiers within the LM2902DT features a high gain bandwidth product and a phase margin of 45 degrees, which ensures stability and reliability in closed-loop applications.

One of the key attributes of the LM2902DT is its ability to operate at low voltage levels, which is essential for portable devices. Additionally, it boasts a low input bias current, which minimizes errors in high-impedance circuit designs. The device also includes internal frequency compensation, which simplifies the design process by eliminating the need for external components to achieve stability.

The LM2902DT's inputs and outputs can operate down to the ground level, which is a significant advantage in single-supply operations. Moreover, the device can drive capacitive loads and can handle phase reversal in case of input overdrive, which contributes to its robust performance in a wide variety of applications.

Applications for the LM2902DT are diverse and include sensor amplifiers, DC gain blocks, and all the conventional Op-Amp circuits. Its ability to handle industrial temperature ranges from -40°C to +105°C makes it suitable for harsh environments. The LM2902DT is also RoHS compliant, adhering to environmental standards regarding hazardous substances.

In summary, the LM2902DT from STMicroelectronics is a reliable and efficient solution for designers looking to incorporate a cost-effective, low-power Op-Amp into their electronic projects. Its quad amplifier configuration, wide supply voltage range, and robust features make it a versatile choice for a multitude of applications.
