Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Memory Format EEPROM
Technology EEPROM
Memory Size 2Mb (256K x 8)
Max Frequency 1MHz
Access Time 450ns
Supply Voltage - Operating 1.8 V to 5.5 V
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 020815-M24M02-DRMN6TP
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name M24M02-DR
Introduction Date March 22, 2011
ECCN 3A991.b.1.b.1
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian M24M02-DRMN6TP CAD Model

Description

STMicroelectronics M24M02-DRMN6TP EEPROM

The M24M02-DRMN6TP from STMicroelectronics is a high-performance 2 Mbit serial I²C bus EEPROM (Electrically Erasable Programmable Read-Only Memory) designed for advanced data storage solutions. This robust memory component is ideal for a wide array of applications, ranging from industrial to consumer electronics, where reliable and efficient non-volatile memory storage is crucial.

Constructed with the latest EEPROM technology, the M24M02-DRMN6TP provides a vast storage space of 2 Mbit, organized as 256 Kbytes of 8 bits each, which is ample for complex applications requiring extensive data logging, user settings, or firmware updates. The device operates within a voltage range of 1.8V to 5.5V, making it versatile for various circuit designs and power requirements.

The M24M02-DRMN6TP features a fast I²C interface that allows for communication speeds of up to 1 Mbit/s, ensuring quick and efficient data transfer. This EEPROM comes in an 8-pin TSSOP package, known for its small footprint and suitability for space-constrained applications. The device also supports a hardware write control feature, which provides an additional layer of data protection against inadvertent writes.

One of the key advantages of this EEPROM is its endurance, with the capability to withstand up to 4 million write cycles per byte, and a data retention period of over 200 years. This ensures the reliability and longevity of the data stored, even under harsh operating conditions.

Furthermore, the M24M02-DRMN6TP is designed with built-in error correction code (ECC) logic that detects and corrects errors automatically, enhancing the integrity of the stored data. The device also includes partial array protection, which allows users to set write protection for specific blocks of memory, providing flexibility and security for sensitive data.

In summary, the STMicroelectronics M24M02-DRMN6TP EEPROM is a highly reliable and versatile memory solution that offers a large storage capacity, fast data transfer rates, and robust data protection features, making it an excellent choice for a multitude of electronic applications.
