Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type Clock/Calendar
Features Leap Year
Date Format YY-MM-DD-dd
Supply Voltage - Operating 2.7 V to 5.5 V
Voltage - Supply, Battery 2 V to 3.5 V
Current - Timekeeping (Max) 70μA @ 2.7V to 5.5V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 020922-M41T00SM6F
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name M41T00
Introduction Date September 08, 2004
ECCN EAR99
Country of Origin Morocco
Halogen Free Not Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian M41T00SM6F CAD Model

Description

STMicroelectronics M41T00SM6F Real-Time Clock

The M41T00SM6F is a low-power serial real-time clock (RTC) with a built-in 32.768 kHz oscillator (external crystal controlled) and an integrated battery backup input. Manufactured by STMicroelectronics, a leader in the semiconductor industry, this RTC is a highly accurate timekeeping device that maintains the time with a precision of ±5 ppm at 25°C.

Its compact surface-mount package makes it ideal for space-constrained applications, and its I²C serial interface facilitates easy integration into various microcontroller-based systems. The M41T00SM6F includes 56 bytes of non-volatile, battery-backed SRAM, which ensures that data is retained even when the main power is lost. This feature is critical for applications that require data logging or retention during power outages.

The device features an automatic power-fail chip deselect and write protection, ensuring data integrity during low power supply conditions. It also supports a clock/calendar function that provides seconds, minutes, hours, day, date, month, and year information. The end of the month date is automatically adjusted for months with fewer than 31 days, including corrections for leap years. It also offers a programmable alarm and square wave output functions, which are valuable for scheduling tasks and periodic wake-up of connected microcontrollers or other ICs.

The M41T00SM6F operates over a wide voltage range (2.7V to 5.5V) and temperature range (-40°C to +85°C), making it suitable for a diverse set of applications including industrial controls, medical devices, utility meters, and consumer electronics. The device's low power consumption ensures minimal impact on battery life, which is crucial for portable and battery-operated devices.

Overall, the M41T00SM6F from STMicroelectronics is a reliable and feature-rich RTC module that provides a cost-effective solution for timekeeping and data retention in electronic systems.
