Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type Clock/Calendar
Features Alarm, Leap Year, Square Wave Output, Watchdog Timer
Date Format YY-MM-DD-dd
Supply Voltage - Operating 2 V to 5.5 V
Voltage - Supply, Battery 2.5 V to 3.5 V
Current - Timekeeping (Max) 100μA @ 2V to 5.5V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 020931-M41T81M6F
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian M41T81M6F CAD Model

Description

The M41T81M6F from STMicroelectronics is a highly integrated, low-power serial real-time clock (RTC) with a built-in 32.768 kHz oscillator (external crystal controlled) and an embedded crystal. This RTC provides a full binary-coded decimal (BCD) clock/calendar that is accessible through an I2C interface.

With a battery backup capability, the M41T81M6F ensures timekeeping operation even when the main power supply is interrupted. The device's clock/calendar provides seconds, minutes, hours, day, date, month, and year information. The end of the month date is automatically adjusted for months with fewer than 31 days, including corrections for leap years. It also operates in either the 24-hour or 12-hour format with an AM/PM indicator.

Featuring an 8-byte, battery-backed SRAM, the M41T81M6F offers additional data storage which is protected during low power supply conditions. The integrated oscillator compensation circuitry provides an excellent timekeeping accuracy over a wide temperature range and compensates for the frequency deviation of the crystal oscillator due to temperature fluctuations.

The device is equipped with additional features such as a programmable alarm and interrupt function that can be set to a specific time or date, providing a versatile mechanism for time-related event management. A programmable square wave output is also available, which can be used for various applications including periodic system wake-ups from a power-saving mode.

The M41T81M6F is housed in an 8-pin SOIC package, making it suitable for space-constrained applications. It is designed to operate over an industrial temperature range of -40°C to +85°C and is ideal for a wide range of applications in consumer electronics, telecommunications, industrial control systems, and embedded systems that require an accurate time base, calendar function, and battery backup capability.

Overall, the M41T81M6F real-time clock from STMicroelectronics is a reliable and feature-rich component that provides precise timekeeping and data storage solutions for sophisticated electronic applications.
