Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Obsolete(EOL)
Logic Type OR Gate
Number of Circuits 4
Number of Inputs 2
Supply Voltage - Operating 2 V to 6 V
Current - Quiescent (Max) 1μA
Current - Output High, Low 5.2mA, 5.2mA
Logic Level - Low 0.5 V to 1.8 V
Logic Level - High 1.5 V to 4.2 V
Max Propagation Delay @ V, Max CL 13ns @ 6V, 50pF
Temperature Range - Operating -55°C to 125°C
Mounting SMD (SMT)
Case / Package 14-SO
Dimension 14-SOIC (0.154", 3.90mm Width)
Win Source Part Number 104450-M74HC32RM13TR
Ultra Librarian 3D Model Ultra Librarian M74HC32RM13TR CAD Model

Description

STMicroelectronics M74HC32RM13TR Quad 2-Input OR Gate

The M74HC32RM13TR is a high-speed CMOS Quad 2-Input OR Gate integrated circuit, expertly designed and manufactured by STMicroelectronics, a global leader in semiconductor solutions. This particular component is part of the HC family, which means it combines silicon-gate CMOS technology with TTL functionality, offering a robust and versatile solution for a wide range of digital applications.

The device is presented in an SO-14 package, a small-outline integrated circuit that offers a compact footprint while still maintaining ease of handling and soldering. The M74HC32RM13TR comes in tape and reel packaging, denoted by the 'TR' suffix, making it suitable for automated assembly processes and high-volume production environments.

Key Features:

  • Logic Type: Quad 2-Input OR Gate, providing logical OR operations for digital circuits.
  • Supply Voltage Range: 2V to 6V, allowing for flexibility in various operating environments and compatibility with TTL levels.
  • High-Speed: Propagation delay time is significantly low, ensuring swift response in critical applications.
  • Low Power Consumption: The device is designed for optimized power usage, contributing to energy-efficient designs.
  • High Noise Immunity: Characterized by a noise immunity that complies with standard specifications, the M74HC32RM13TR is robust against environmental disturbances.
  • Output Drive Capability: Capable of driving 10 LSTTL loads, which demonstrates its strong output drive performance.

Applications:

The M74HC32RM13TR is suitable for a diverse array of applications, including but not limited to:

  • Computing systems
  • Data processing
  • Control systems
  • Embedded systems
  • Signal processing
  • Logic interface

With its combination of high-speed operation, low power consumption, and compatibility with existing TTL-based systems, the M74HC32RM13TR from STMicroelectronics is an excellent choice for designers looking to implement reliable and efficient OR logic functions in their digital circuit designs.
