Products specifications

Categories Circuit Protection
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type Zener
Bidirectional Channels 1
STAND-OFF Voltage (Vwm) 28.2V
Minimum Breakdown Voltage 31.4V
Max Clamping Voltage 59V
Peak Pulse Current(Ippm) 68A (8/20μs)
Power Dissipation - Pd 600W
Applications Automotive
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SMB (DO-214AA)
Win Source Part Number 028972-SM6T33CAY
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name SM6T33CAY
Introduction Date September 15, 2010
ECCN EAR99
Country of Origin China, Morocco
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian SM6T33CAY CAD Model

Description

The SM6T33CAY from STMicroelectronics is a Transil diode designed to provide high overvoltage protection by clamping action. Its bidirectional, transient voltage suppression (TVS) capability makes it an efficient solution for safeguarding sensitive electronic components against voltage transients induced by inductive load switching and lightning disruptions.

Key Features

  • Stand-off Voltage: The device has a stand-off voltage of 33V, making it suitable for a range of applications that require this level of voltage protection.
  • Peak Pulse Power: It offers a peak pulse power dissipation of 600W (10/1000 μs surge), ensuring the protection of vulnerable circuits during transient conditions.
  • Package: The SM6T33CAY is housed in a molded plastic SMB (DO-214AA) package, which provides a compact footprint and is suitable for automated assembly processes.
  • Low Clamping Factor: With a low clamping factor, the device ensures minimal voltage overshoot during transient events, thus offering better protection for sensitive components.
  • Operating Temperature Range: The device operates effectively over a wide temperature range from -40°C to +150°C, making it ideal for harsh environmental conditions.

Applications

The SM6T33CAY is versatile and can be used in a variety of applications, including:

  • Power supply protection
  • AC/DC applications
  • Telecommunication devices
  • Computer systems
  • Industrial electronics

Reliability and Safety

The device meets the ISO 7637-2 and ISO 16750-2 standards for automotive protection, ensuring reliability and safety for use in automotive environments. Additionally, it complies with IEC 61000-4-2 and IEC 61000-4-5 surge immunity tests, which guarantees robustness against electrostatic discharges and surge transients.

In summary, the SM6T33CAY from STMicroelectronics is a robust and reliable solution for protecting electronic circuits from voltage spikes and surges. Its combination of high surge capability, compact design, and compliance with international standards makes it an excellent choice for designers looking to enhance the durability and longevity of their electronic products.
