Products specifications

Manufacturer STMicroelectronics
Packaging Reel
Part Status Obsolete (End Of Life)
Core Processor ST7
Core Size 8-Bit
Speed 16MHz
Connectivity LINbusSCI, SPI
Peripherals LVD, POR, PWM, WDT
Number of I/O 15
Program Memory Size 8KB (8K x 8)
Program Memory Type FLASH
RAM Size 384 x 8
Voltage - Supply (Vcc/Vdd) 2.7V ~ 5.5V
Data Converters A/D 7x10b
Oscillator Type Internal
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 20-VQFN Exposed Pad
Supplier Device Package 20-QFN (6x5)
Part Number Series ST7FL
Manufacturer Pack Quantity 3,000
MSL Level 3 (168 Hours)
Popularity High
Supply and Demand Status Balance
Win Source Part Number 802326-ST7FLITE35U6TR
Ultra Librarian 3D Model Ultra Librarian ST7FLITE35U6TR CAD Model

Description

ST7FLITE35U6TR Microcontroller from STMicroelectronics

The ST7FLITE35U6TR is a high-performance microcontroller unit (MCU) from STMicroelectronics, designed for a wide range of applications requiring a balance between power efficiency and processing capability. This MCU is part of the ST7 family, which is well-regarded for its robust architecture, versatile features, and ease of use.

At the heart of the ST7FLITE35U6TR is an 8-bit CPU core operating at a maximum frequency of 8 MHz, which is capable of executing up to 5 MIPS (Million Instructions Per Second). This processing power is suitable for handling complex algorithms and control tasks in embedded systems. The device comes in a compact 20-pin SOIC package, making it ideal for space-constrained applications.

One of the standout features of this MCU is its 4 Kbytes of Flash program memory, which is highly reliable and allows for in-circuit programming and reprogramming, facilitating rapid development and updates. Alongside this, the ST7FLITE35U6TR offers 128 bytes of RAM and 128 bytes of data EEPROM, which provides efficient data storage and retention capabilities.

For connectivity and control, the MCU includes an array of peripherals. It has 10 I/O pins, a 10-bit analog-to-digital converter (ADC) with 3 channels, allowing for precise measurement of analog signals. A single 8-bit timer with prescaler, real-time base, and watchdog capability provides timing and system integrity functions. The MCU also supports a synchronous serial communication (SPI) interface, which enables communication with other microcontrollers, sensors, and peripheral devices.

Enhanced features such as low voltage detection, an Auto Wake Up (AWU) feature from halt mode, and an integrated oscillator make the ST7FLITE35U6TR a versatile choice for low-power applications. The MCU operates over a wide voltage range of 3.0V to 5.5V, further underlining its flexibility in various operating environments.

STMicroelectronics provides comprehensive development tools and software support for the ST7FLITE35U6TR, including the ST Visual Develop (STVD) Integrated Development Environment (IDE) and the ST Visual Programmer (STVP). These tools facilitate a streamlined development process, from initial design through to final programming and deployment.

In summary, the ST7FLITE35U6TR microcontroller is an efficient and versatile solution for designers looking to optimize their embedded systems with a reliable and feature-rich MCU.
