Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Obsolete(EOL)
Purpose Step-Up/Step-Down
Topology Buck-Boost
Output Type Adjustable
Number of Outputs 1
Minimum Input Voltage 2V
Maximum Input Voltage 5.5V
Nominal Output Voltage (Min/Fixed) 1.2V
Maximum Output Voltage 5.5V
Output Current 1.6A (Switch)
Frequency - Switching 1.5MHz
Synchronous Rectifier Yes
Temperature Range - Operating -40°C to 85°C (TJ)
Mounting SMD (SMT)
Case / Package 10-DFN (3x3)
Win Source Part Number 109496-STBB1PUR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian STBB1PUR CAD Model

Description

The STBB1PUR from STMicroelectronics is a highly efficient, single-channel, step-down switching regulator that is designed to deliver a constant, regulated output voltage with a high level of accuracy. This regulator is part of STMicroelectronics' extensive portfolio of power management devices, which are renowned for their reliability and performance in a wide range of applications.

Key Features

  • Output Voltage Range: The STBB1PUR provides an adjustable output voltage range, ensuring versatility for various design requirements.
  • High Efficiency: With its advanced design, this regulator maintains high efficiency across a wide range of load conditions, making it ideal for battery-powered applications.
  • Low Quiescent Current: The device features a low quiescent current that extends battery life by minimizing power consumption when the device is in standby mode.
  • Thermal Protection: It includes thermal shutdown protection, which prevents damage to the regulator and the application in case of excessive temperature rise.
  • Current Limiting: Built-in current limiting enhances the safety and reliability of the regulator by preventing overcurrent conditions.

Applications

The versatility of the STBB1PUR makes it suitable for a wide array of applications, including but not limited to:

  • Consumer Electronics
  • Portable Devices
  • Power Management Solutions
  • Industrial Controls
  • Networking Equipment

Package and Availability

The STBB1PUR is available in a compact package that is designed for easy integration into various circuit designs. The package is optimized for thermal performance and space-saving on the PCB. For pricing, availability, and additional technical specifications, interested parties are encouraged to visit the STMicroelectronics website or contact their sales representatives.

In conclusion, the STBB1PUR step-down switching regulator from STMicroelectronics stands out with its high efficiency, adjustable output voltage, and advanced protection features, making it an excellent choice for designers looking to optimize power management in their electronic projects.
