Products specifications

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Reel
Transistor Polarity N-Channel
Technology MOSFET
Vds - Drain-Source Breakdown Voltage 300V
Id - Continuous Drain Current 10A
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Maximum) at Id, Vgs 330mOhm at 5A, 10V
Gate Source Voltage(th) (Maximum) at Id 4V at 250μA
Gate Charge (Qg) (Maximum) at Vgs 23nC at 10V
Gate Source Voltage (Maximum) ±20V
Input Capacitance (Ciss) (Maximum) at Vds 780pF at 25V
Power Dissipation (Maximum) 103W
Temperature Range - Operating -55°C ~ 175°C
Mounting Style SMD
Supplier Device Package DPAK
Manufacturer Package TO-252-3, DPak (2 Leads + Tab), SC-63
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 1260755-STD10NF30
Manufacturer Homepage www.st.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian STD10NF30 CAD Model

Description

Introducing the STD10NF30 MOSFET from STMicroelectronics

The STD10NF30 is a cutting-edge N-channel MOSFET brought to you by STMicroelectronics, a global leader in semiconductor solutions. This high-performance MOSFET is designed to deliver outstanding efficiency and power handling capabilities, making it an ideal choice for a wide range of electronic applications.

The STD10NF30 features state-of-the-art MDmesh™ technology, which combines low on-resistance (R<sub>DS(on)) with high switching speed. This technology ensures that the device operates with reduced conduction losses and improved overall efficiency, which is critical for power-intensive applications. The MOSFET is encapsulated in a robust and compact DPAK package, which not only facilitates efficient heat dissipation but also allows for a smaller footprint on the PCB.

With a drain-source voltage (V<sub>DS) of 30V and a continuous drain current (I<sub>D) of 10A, the STD10NF30 is capable of handling high current loads while maintaining a low threshold voltage, ensuring that the device is easily driven and controlled. The low gate charge (Q<sub>g) characteristic of this MOSFET translates into faster switching performance, which is beneficial for applications requiring high-speed operation.

One of the key applications of the STD10NF30 is in the realm of power management, where it can be used in DC-DC converters, motor drives, and other power conversion systems. Its efficiency and reliability also make it suitable for automotive applications, where performance and durability are of paramount importance.

STMicroelectronics has designed the STD10NF30 with not only performance in mind but also with a commitment to environmental sustainability. The device is fully compliant with RoHS and Halogen-free directives, ensuring that it meets the latest environmental standards for electronic components.

In summary, the STD10NF30 from STMicroelectronics is a high-performance, efficient, and reliable N-channel MOSFET that brings together the latest in semiconductor technology with a commitment to environmental responsibility. Its versatile features and robust design make it an excellent choice for designers looking to optimize their power management and conversion systems.
