SPD04N60C3 Real Image SPD04N60C3 Real Image
Same model may have multiple batches, images only for reference.
SPD04N60C3 Real Image SPD04N60C3 Real Image
SPD04N60C3 Real Image SPD04N60C3 Real Image
Same model may have multiple batches, images only for reference.

SPD04N60C3

Part No SPD04N60C3
Manufacturer Infineon Technologies
Catalog FETs - Single
Description Trans MOSFET N-CH 600V 4.5A 3-Pin(2+Tab) DPAK T/R / Cool MOS Power Transistor | MOSFET N-CH 600V 4.5A TO252-3
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube
Status Obsolete
Transistor Polarity N-Channel
Technology MOSFET
Vds - Drain-Source Breakdown Voltage 600V
Id - Continuous Drain Current 4.5A
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Maximum) at Id, Vgs 950mOhm at 2.8A, 10V
Gate Source Voltage(th) (Maximum) at Id 3.9V at 200μA
Gate Charge (Qg) (Maximum) at Vgs 25nC at 10V
Gate Source Voltage (Maximum) ±20V
Input Capacitance (Ciss) (Maximum) at Vds 490pF at 25V
Power Dissipation (Maximum) 50W
Temperature Range - Operating -55°C ~ 150°C
Mounting Style SMD
Supplier Device Package PG-TO252-3
Manufacturer Package TO-252-3, DPak (2 Leads + Tab), SC-63
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 1257868-SPD04N60C3
Manufacturer Homepage www.infineon.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name SPD04N60C3
Introduction Date July 25, 2002
ECCN EAR99
Country of Origin China, Malaysia, Philippines
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian SPD04N60C3 CAD Model

Description

The SPD04N60C3 is a MOSFET transistor manufactured by Infineon Technologies.

  • Transistor Polarity: N-Channel
  • Family: SPD04N60C3
  • Drive Voltage: 10V
  • Power Dissipation: 50W
  • Drain-Source Breakdown Voltage: 600V
  • Continuous Drain Current: 4.5A
  • Rds On (Maximum) @ Id, Vgs: 950mOhm @ 2.8A, 10V
  • Gate Source Voltage(th) (Maximum) @ Id: 3.9V @ 200μA
  • Gate Charge (Qg) (Maximum) @ Vgs: 25nC @ 10V
  • Input Capacitance (Ciss) (Maximum) @ Vds: 490pF @ 25V
  • Popularity: High
  • Compliance: Halogen-free compliant
  • Estimated EOL Date: 2027
  • Packaging: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Status: Obsolete
