Products specifications

Category Development Boards, Kits, Programmers>Evaluation Boards - Sensors
Mfr STMicroelectronics
Package Bulk
Product Status Obsolete
Sensor Type Temperature
Sensing Range -55°C ~ 125°C
Interface I2C
Voltage - Supply 7.5V ~ 19V
Embedded Yes, MCU, 8-Bit
Supplied Contents Board(s)
Utilized IC / Part ST72F651, STDS75, STLM75
Other Names 497-6238,-497-6238,STEVALIFS003V1
Standard Package 1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN 3A991A2
HTSUS 8473.30.5100
Win Source Part Number 1283690-STEVAL-IFS003V1
Ultra Librarian 3D Model Ultra Librarian STEVAL-IFS003V1 CAD Model

Description

STEVAL-IFS003V1 - STMicroelectronics Evaluation Board

The STEVAL-IFS003V1 from STMicroelectronics is a state-of-the-art evaluation board designed for testing the performance and capabilities of the SPV1020, a highly efficient, interleaved boost converter dedicated to photovoltaic applications. This evaluation board is an excellent tool for engineers and developers looking to explore the features and integrations of the SPV1020 in a solar panel setup.

Key Features

  • Integrated SPV1020 interleaved boost converter for efficient solar energy harvesting
  • Capability to connect multiple solar panels in series, enhancing the output voltage range
  • Maximum Power Point Tracking (MPPT) algorithm implemented to maximize the energy extraction under various environmental conditions
  • Overcurrent and overvoltage protection features to ensure the safety and durability of the system
  • LED indicators for real-time monitoring of the operation status
  • Easy-to-use connectors for quick setup and testing
  • Provision for external load connection to simulate real-world applications

Applications

The STEVAL-IFS003V1 evaluation board is ideally suited for a range of applications including:

  • Renewable energy systems, particularly solar energy harvesting
  • Industrial and residential photovoltaic installations
  • Remote power systems where grid electricity is not available
  • Experimental and educational projects focusing on green energy solutions

Design Advantages

The evaluation board's design is optimized for flexibility and ease of use, enabling rapid prototyping and experimentation. With the inclusion of the SPV1020, the STEVAL-IFS003V1 offers an excellent platform for developing high-efficiency solar power solutions. The board's robust protection features and MPPT algorithm make it a reliable choice for testing under various conditions, ensuring that users can maximize the potential of their solar panels while safeguarding their system components.

Overall, the STEVAL-IFS003V1 is an invaluable tool for anyone looking to delve into the realm of photovoltaic energy conversion, offering a practical and user-friendly interface for exploring the capabilities of STMicroelectronics' innovative SPV1020 boost converter.
