Products specifications

Category Development Boards, Kits, Programmers>Evaluation Boards - Sensors
Mfr STMicroelectronics
Package Box
Product Status Obsolete
Sensor Type Proximity
Interface Analog
Voltage - Supply 24V
Embedded No
Supplied Contents Board(s)
Utilized IC / Part TDA0161
Other Names 497-6455
Standard Package 1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8471.41.0150
Win Source Part Number 1283736-STEVAL-IFS007V1
Ultra Librarian 3D Model Ultra Librarian STEVAL-IFS007V1 CAD Model

Description

STEVAL-IFS007V1 - Smart Power Module from STMicroelectronics

The STEVAL-IFS007V1 is a sophisticated smart power module designed and manufactured by STMicroelectronics, a global leader in semiconductor solutions. This module is part of ST's SLLIMM™ (Small Low-Loss Intelligent Molded Module) family and is specifically engineered to deliver high efficiency and reliability for motor drive applications.

Key Features

  • Integrated Smart Power System: The module combines IGBTs, freewheeling diodes, and a gate driver in a single package, simplifying design and reducing time-to-market for various applications.
  • Advanced IGBT Technology: Utilizes ST's state-of-the-art IGBT technology to provide excellent performance in terms of efficiency and thermal management, making it suitable for high-power density applications.
  • Compact Design: The compact footprint of the module allows for a reduction in PCB size and overall system cost, making it ideal for space-constrained applications.
  • Over-temperature Protection: Equipped with an over-temperature shutdown feature, the module ensures additional safety and longevity of the motor drive system.
  • Under-voltage Lockout: The built-in under-voltage lockout (UVLO) function protects the IGBTs from operating at insufficient voltages, which could otherwise lead to inefficient performance or damage.
  • Short-circuit Rated IGBTs: Provides robustness and reliability in harsh operating conditions by being able to handle short-circuit events.

Applications

The STEVAL-IFS007V1 is versatile and can be used in a wide range of applications, including:

  • Home appliances (such as washing machines and refrigerators)
  • Fans and pumps
  • Industrial drives
  • General-purpose inverters
  • Power tools

Technical Specifications

With its robust design and comprehensive protection features, the STEVAL-IFS007V1 is an excellent choice for designers looking to create efficient and reliable motor control systems. The module's technical specifications include a broad input voltage range, high current handling capabilities, and compatibility with various control methodologies, including PWM (Pulse Width Modulation).

For detailed information on the STEVAL-IFS007V1, including datasheets, technical documentation, and application notes, visit STMicroelectronics' official website or contact their support team for further assistance.
