Products specifications

Category Development Boards, Kits, Programmers>Evaluation and Demonstration Boards and Kits
Mfr STMicroelectronics
Series SLLIMM™
Package Bulk
Type Power Management
Function Motor Controller/Driver
Utilized IC / Part STGIPQ3H60T-H
Supplied Contents Board(s)
Secondary Attributes On-Board LEDs, Test Points
Base Product Number STEVAL
Other Names 497-17205
Standard Package 1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8473.30.1180
Win Source Part Number 1284461-STEVAL-IPMNG3Q
Ultra Librarian 3D Model Ultra Librarian STEVAL-IPMNG3Q CAD Model

Description

The STEVAL-IPMNG3Q is an advanced power management integrated module designed by STMicroelectronics, a leader in semiconductor solutions. This product is part of ST's SLLIMM™-nano series, which stands for Small Low-Loss Intelligent Molded Module, and is specifically engineered to provide a compact and high-performance solution for motor drive applications.

Key Features

  • High Integration: The STEVAL-IPMNG3Q integrates a three-phase inverter with a gate driver, bootstrap diodes, and short-circuit rated IGBTs, streamlining the design process and reducing the overall footprint of motor drive circuits.
  • Advanced IGBT Technology: Utilizing the latest IGBT technology, the module offers excellent power efficiency and thermal performance, making it suitable for a wide range of operating conditions.
  • Overcurrent Protection: Built-in overcurrent protection ensures the longevity and reliability of the module by preventing damage from unexpected current spikes.
  • Under-voltage Lockout: The integrated under-voltage lockout feature safeguards the module against operation at insufficient voltages which could lead to inefficient performance or damage.
  • Compact Design: With its small footprint, the STEVAL-IPMNG3Q is ideal for applications where space is at a premium, without compromising on power or efficiency.

Applications

The STEVAL-IPMNG3Q is versatile and can be used in various applications, including:

  • Home appliances such as washing machines and refrigerators
  • Fans and HVAC systems
  • Small electric drives, including pumps and compressors
  • Light industrial applications

Easy to Use

The module is designed for ease of use, with a simple layout that allows for straightforward integration into existing designs. It is also supported by a range of evaluation boards and development kits from STMicroelectronics, which provide a quick and efficient way to test and implement the STEVAL-IPMNG3Q in any motor control application.

The STEVAL-IPMNG3Q is a testament to STMicroelectronics' commitment to providing innovative and high-quality components for the industrial and consumer markets. By choosing STEVAL-IPMNG3Q, designers can expect improved system reliability, optimized performance, and reduced time-to-market for their motor control solutions.
