Products specifications Report Issue?

Category Development Boards, Kits, Programmers>Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS
Mfr STMicroelectronics
Series VIPER™
Package Bulk
Product Status Obsolete
Main Purpose AC/DC, Primary Side
Outputs and Type 3, Isolated
Power - Output 28 W
Voltage - Output 3.3V, 7V, 12V
Current - Output 2A, 1A, 200mA
Voltage - Input 90 ~ 265 VAC
Regulator Topology Flyback
Frequency - Switching 40kHz
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part VIPer53
Other Names -497-8435,497-8435,STEVALISA008V1,STEVAL-ISA008V1
Standard Package 1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8473.30.1180
Win Source Part Number 1284154-STEVAL-ISA008V1
Ultra Librarian 3D Model Ultra Librarian STEVAL-ISA008V1 CAD Model

Description

STEVAL-ISA008V1 - STMicroelectronics Demonstration Board

The STEVAL-ISA008V1 is a highly efficient demonstration board from STMicroelectronics, designed to showcase the capabilities of the L5983, a step-down monolithic power switching regulator capable of delivering up to 3 A of current. This product is specifically engineered for a wide range of applications, including industrial, automotive, and consumer electronics, where power efficiency and reliability are paramount.

With an input voltage range of 4.4 V to 36 V, the STEVAL-ISA008V1 is versatile and suitable for operating in various supply conditions, ensuring consistent performance even in fluctuating power environments. The board is equipped with a fixed 400 kHz switching frequency, which allows for a balanced compromise between efficiency and the size of external components, making it an ideal solution for compact designs.

The demonstration board comes with several key features that enhance its performance and user experience. These features include:

  • An adjustable output voltage from 0.8 V to VIN, which provides flexibility in powering different loads and adapting to specific application requirements.
  • Internal soft-start and enable functions that ensure a smooth startup and allow power sequencing.
  • Thermal shutdown and overcurrent protection, which safeguard the board from damage caused by excessive heat or current.
  • Pulse-by-pulse current limiting, which enhances the reliability and longevity of the power regulator under extreme operating conditions.

The STEVAL-ISA008V1 is not only a testament to STMicroelectronics' commitment to high-quality power management solutions but also serves as an excellent tool for designers to evaluate the L5983 regulator in their own applications. The board's layout is optimized to minimize noise and electromagnetic interference, ensuring stable operation even in noise-sensitive applications.

Overall, the STEVAL-ISA008V1 is an exemplary demonstration board that combines robustness, efficiency, and versatility, making it an invaluable resource for engineers seeking to implement advanced power solutions in their designs.
