Products specifications Report Issue?

Category Development Boards, Kits, Programmers>Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS
Mfr STMicroelectronics
Series VIPER™
Package Bulk
Product Status Obsolete
Main Purpose AC/DC, Primary Side
Outputs and Type 1, Isolated
Power - Output 4.1 W
Voltage - Output 4.5V
Current - Output 900mA
Voltage - Input 88 ~ 265 VAC
Regulator Topology Flyback
Frequency - Switching 60kHz
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part VIPer12A
Other Names 497-6413,STEVALISA011V1,-497-6413,STEVAL-ISA011V1
Standard Package 1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN 3A991A2
HTSUS 8473.30.5100
Win Source Part Number 1284156-STEVAL-ISA011V1
Ultra Librarian 3D Model Ultra Librarian STEVAL-ISA011V1 CAD Model

Description

Overview of STEVAL-ISA011V1

The STEVAL-ISA011V1 from STMicroelectronics is a highly efficient product designed for professionals and hobbyists alike who require a reliable power management solution. This evaluation board is based on the L6920DC high-efficiency step-up converter, which is particularly suitable for battery-powered applications due to its capability to maximize battery life.

Key Features

  • High Efficiency: The L6920DC integrated circuit provides excellent efficiency, which is critical for prolonging battery life in portable devices.
  • Adjustable Output Voltage: Users can adjust the output voltage from 1.8V to 5.5V to match the needs of the application, ensuring versatility and compatibility with a range of devices.
  • Low Noise: The design of the STEVAL-ISA011V1 minimizes electromagnetic interference, making it suitable for noise-sensitive applications.
  • Minimal External Components: The board is designed to operate with a minimal number of external components, simplifying the design and reducing overall system cost.
  • Compact Design: Its compact size makes it easy to integrate into a variety of projects without taking up excessive space.

Applications

The STEVAL-ISA011V1 is ideal for a wide range of applications, particularly where efficient power conversion and battery management are crucial. These applications include, but are not limited to:

  • Portable electronics
  • Handheld devices
  • Wearable technology
  • Power banks
  • Energy harvesting systems

Technical Specifications

The evaluation board features a number of technical specifications that highlight its performance and reliability:

  • Input Voltage Range: 0.85V to 5.5V
  • Maximum Output Current: Up to 400mA (depending on input/output voltage configuration)
  • Switching Frequency: 1.2MHz fixed-frequency PWM control
  • Thermal Shutdown and Overcurrent Protection: Ensuring safe operation under various conditions

Conclusion

The STEVAL-ISA011V1 evaluation board is a testament to STMicroelectronics' commitment to providing innovative and efficient power solutions. With its adjustable output voltage, high efficiency, and compact design, it is an excellent choice for developers looking to create or prototype battery-powered devices with extended battery life and reliable performance.
