Products specifications Report Issue?

Categories Development Boards, Kits, Programmers
Manufacturer STMicroelectronics
Part Status Obsolete(EOL)
Main Purpose DC/DC, Step Down
Outputs and Type 1, Non-Isolated
Voltage - Output 5V
Output Current 3A
Voltage - Input 125 V ~ 1250 V
Regulator Topology Buck
Frequency - Switching 30kHz
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part L6565, STC03DE220HV
Win Source Part Number 795593-STEVAL-ISA057V1
Popularity Medium
Supply and Demand Status Sufficient
Family Name STEVAL-ISA057V1
Introduction Date June 22, 2005
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian STEVAL-ISA057V1 CAD Model

Description

The STEVAL-ISA057V1 from STMicroelectronics is a highly efficient evaluation board designed for power supply solutions. This compact and versatile board is based on the VIPer17 high voltage converter, which integrates a PWM controller and a 730 V rugged power MOSFET, making it ideal for a wide range of applications including auxiliary power supplies and switch mode power supplies (SMPS).

This evaluation board is specifically tailored for flyback converters, providing a straightforward platform to test and validate designs before moving to production. It supports both isolated and non-isolated topologies, allowing developers to experiment with different configurations to suit their specific application needs.

Key features of the STEVAL-ISA057V1 include:

  • Input voltage range from 85 V to 265 V AC, accommodating a wide array of global power standards.
  • Output voltage of 12 V DC, with an output power up to 5 W, suitable for a variety of low-power applications.
  • Integrated error amplifier and oscillator, simplifying the design and reducing external component count.
  • Overcurrent and overvoltage protection, ensuring the longevity and reliability of both the board and the end application.
  • Thermal shutdown with automatic restart, providing an additional layer of protection against overheating.

The board's compact size and comprehensive feature set make it an excellent choice for designers looking to create efficient and reliable power supply circuits with minimal hassle. Whether it's for consumer electronics, industrial controls, or home appliances, the STEVAL-ISA057V1 offers a solid foundation for developing power solutions.

STMicroelectronics provides detailed documentation and design resources, including schematics, bill of materials, and application notes, which help to accelerate the development process and reduce time to market.

With the STEVAL-ISA057V1, engineers and designers can confidently approach their power supply projects, assured of a high-performance, cost-effective solution backed by the renowned quality and support of STMicroelectronics.
