Products specifications Report Issue?

Category Development Boards, Kits, Programmers>Evaluation and Demonstration Boards and Kits
Mfr STMicroelectronics
Package Bulk
Type Power Management
Function Battery Charger
Embedded No
Utilized IC / Part L6924D
Primary Attributes Li-Ion / Li-Pol (1 Cell)
Supplied Contents Board(s)
Base Product Number STEVAL
Other Names STEVALISA076V1,497-11036
Standard Package 1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8473.30.1180
Win Source Part Number 1284588-STEVAL-ISA076V1
Ultra Librarian 3D Model Ultra Librarian STEVAL-ISA076V1 CAD Model

Description

STEVAL-ISA076V1 Product Overview

The STEVAL-ISA076V1 from STMicroelectronics is a highly efficient, fully integrated power supply module designed to meet the demands of modern compact electronic applications. This product is part of ST's VIPerPlus series, which stands out for its energy-saving features and robustness. The STEVAL-ISA076V1 is a demonstration board that utilizes the VIPer06HS high-voltage converter with a fixed 115 kHz switching frequency, enabling designers to evaluate the performance of this advanced power solution.

Key Features

  • High Efficiency: The STEVAL-ISA076V1 is designed for high energy efficiency, which helps reduce power consumption and heat dissipation in end applications.
  • Integrated Features: This evaluation board includes an 800 V avalanche-rugged power section, PWM operation at 115 kHz with frequency jittering for lower EMI, and a standby power consumption lower than 50 mW at 265 VAC.
  • Wide Input Voltage Range: It supports a wide range of input voltages from 85 VAC to 265 VAC, making it suitable for universal mains.
  • Compact Design: The board's small form factor is optimized for space-sensitive applications.
  • Isolated Flyback: The STEVAL-ISA076V1 operates in isolated flyback topology, which ensures electrical isolation between the input and the output.

Applications

The STEVAL-ISA076V1 is ideal for a variety of applications where efficient power conversion and compactness are critical. It is particularly well-suited for:

  • Home appliances
  • Building automation
  • Industrial control systems
  • Consumer electronics
  • Smart metering

Design Support

STMicroelectronics provides extensive support for the STEVAL-ISA076V1, including detailed documentation, reference design files, and technical support from their engineering team. This enables designers to rapidly integrate the power supply module into their projects with minimal effort and to customize it to fit their specific needs.

Overall, the STEVAL-ISA076V1 is a testament to STMicroelectronics' commitment to providing innovative, high-performance power solutions that are ready to power the next generation of electronic devices.
