Products specifications

Category Development Boards, Kits, Programmers>Evaluation and Demonstration Boards and Kits
Mfr STMicroelectronics
Package Bulk
Product Status Obsolete
Type Interface
Function PMBus
Embedded Yes, MCU, 8-Bit
Utilized IC / Part ST72F264
Primary Attributes The PMBus™ Interface Using the ST7 I²C Peripheral
Supplied Contents Board(s)
Secondary Attributes Firmware in C Language
Other Names -497-6423,497-6423
Standard Package 1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8471.41.0150
Win Source Part Number 1284535-STEVAL-ISQ002V1
Ultra Librarian 3D Model Ultra Librarian STEVAL-ISQ002V1 CAD Model

Description

STEVAL-ISQ002V1 Energy Harvesting Evaluation Board

The STEVAL-ISQ002V1 from STMicroelectronics is a cutting-edge energy harvesting evaluation board specifically designed for low-power applications. It is a part of ST's portfolio of evaluation tools that allow designers to assess the capabilities and performance of energy harvesting technologies in converting ambient energy into electrical energy.

This innovative evaluation board is built around the SPV1050, an ultra-low power and high-efficiency energy harvester and battery charger, which ensures maximum energy extraction from various sources such as solar, vibration, or thermal energy. The SPV1050 operates in either boost or buck-boost mode, making it versatile for a wide range of input sources and storage elements like rechargeable batteries or capacitors.

The STEVAL-ISQ002V1 board includes a solar panel, making it ready to use for solar energy harvesting experiments right out of the box. It also features a battery holder for a rechargeable lithium battery, demonstrating its capability to store harvested energy for later use. This is particularly useful for powering small IoT devices, wearable technology, and wireless sensors where power supply constraints are a concern.

Equipped with jumpers and test points, the board offers flexibility and convenience for monitoring and optimizing the energy harvesting parameters. Engineers can easily evaluate the performance of the SPV1050 and experiment with different configurations to match their specific application needs.

Key features of the STEVAL-ISQ002V1 include:

  • SPV1050 high-efficiency ultralow power energy harvester and battery charger
  • Configurable for boost or buck-boost operation
  • Integrated solar panel for immediate energy harvesting experimentation
  • Battery holder for lithium battery to store harvested energy
  • Multiple jumpers and test points for easy measurement and configuration
  • Compact design suitable for prototyping a variety of low-power applications

Overall, the STEVAL-ISQ002V1 is an excellent platform for engineers and developers looking to explore energy harvesting solutions that can lead to more sustainable and maintenance-free electronic systems. Its ease of use and comprehensive features make it an ideal starting point for developing energy-autonomous devices for the future.
