Products specifications

Category Development Boards, Kits, Programmers>Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS
Mfr STMicroelectronics
Package Bulk
Product Status Obsolete
Main Purpose Special Purpose DC/DC, Power Over Ethernet
Outputs and Type 2, Isolated
Power - Output 10 W
Voltage - Output 1.2V, 3.3V
Current - Output 650mA, 650mA
Voltage - Input 48V
Regulator Topology Buck
Frequency - Switching 30kHz
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part L6565
Other Names 497-6427,STEVALTSP001V1,STEVAL-TSP001V1,1026-STEVAL-TSP001V1,-497-6427
Standard Package 1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8471.41.0150
Win Source Part Number 1284205-STEVAL-TSP001V1
Ultra Librarian 3D Model Ultra Librarian STEVAL-TSP001V1 CAD Model

Description

STEVAL-TSP001V1 - STMicroelectronics' Energy Harvesting Solution

The STEVAL-TSP001V1 from STMicroelectronics is a state-of-the-art energy harvesting solution designed to power small electronic devices through the collection and conversion of ambient energy sources. This innovative product is part of ST's portfolio of energy management devices that focus on sustainability and efficiency.

Key Features:

  • Integrated Energy Harvester: The board incorporates an advanced energy harvester capable of converting light, vibration, or thermal differences into electrical energy, ensuring a reliable power source for low-power applications.
  • Ultra-Low-Power Design: It is optimized for minimal power consumption, making it ideal for remote, wireless, and maintenance-free applications where conventional power sources are impractical or unavailable.
  • MPPT Functionality: The Maximum Power Point Tracking (MPPT) algorithm maximizes the efficiency of energy collection from variable ambient sources, ensuring optimal charging and extended life for the connected energy storage element.
  • Energy Storage Management: The device features smart energy storage management, which safely charges and protects onboard energy storage elements like rechargeable batteries or supercapacitors.
  • Flexible Power Outputs: Multiple regulated voltage outputs are provided to accommodate a variety of sensors and microcontrollers, making it a versatile solution for numerous applications.

Applications:

The STEVAL-TSP001V1 is ideal for a wide range of applications, including but not limited to:

  • Wireless sensor nodes
  • Wearable technology
  • Environmental monitoring systems
  • Building and home automation
  • Industrial monitoring and control

Conclusion:

With its cutting-edge technology and focus on energy efficiency, the STEVAL-TSP001V1 represents a leap forward in the field of energy harvesting. It provides designers and engineers with a powerful tool to create innovative, self-sustaining electronic systems that are both environmentally friendly and cost-effective over the long term. By leveraging ambient energy sources, this solution paves the way for the development of new applications where power availability is a critical concern.
