Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Tray
Status Active
Core Processor ARM Cortex-M3
Part Core Size 32-Bit
Speed(Frequency) 24MHz
Number of I/O 37
Program Memory Size 64KB (64K x 8)
Program Memory Type FLASH
Data RAM Size 8K x 8
Supply Voltage - Operating 2 V to 3.6 V
Data Converters A/D 10x12b; D/A 2x12b
Temperature Range - Operating -40°C to 85°C (TA)
Dimension 48-LQFP
Win Source Part Number 031253-STM32F100C8T6B
Family Name STM32F100C8
Introduction Date October 12, 2009
ECCN EAR99
Country of Origin United States of America
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Portable Devices, Medical, Consumer Electronics, Computers & Computer Peripherals, Communications & Networking, Industrial, Security, Imaging, Video & Vision, HVAC
Ultra Librarian 3D Model Ultra Librarian STM32F100C8T6B CAD Model

Description

STM32F100C8T6B Microcontroller – STMicroelectronics

The STM32F100C8T6B is a high-performance, low-power 32-bit microcontroller from STMicroelectronics, which is part of the STM32 Value Line series. This microcontroller is based on the ARM Cortex-M3 processor core and is designed to offer an economical solution for a wide range of applications.

Featuring a maximum CPU frequency of 24 MHz, the STM32F100C8T6B provides a balanced combination of computing power and energy efficiency. It comes with 64 KB of Flash memory and 8 KB of SRAM, which are sufficient for various embedded system applications. The device operates within a voltage range of 2.0 to 3.6V, making it suitable for battery-powered and portable devices.

With its rich set of peripherals, the STM32F100C8T6B is highly versatile. It includes multiple communication interfaces such as I2C, USARTs, SPIs, and CAN, allowing for easy integration into communication networks. The microcontroller also features 12-bit analog-to-digital converters (ADCs) for accurate analog signal acquisition, along with general-purpose timers, and PWM capability for motor control and other timing-critical applications.

The STM32F100C8T6B supports an extensive set of power-saving modes, including Sleep, Stop, and Standby, which enable the design of energy-efficient applications. The device's robust design includes a temperature range from -40°C to +85°C, ensuring reliable operation even in harsh environmental conditions.

Developers can take advantage of the STM32 comprehensive development ecosystem, which includes development boards, software libraries, and the STM32CubeMX configuration tool, to streamline the development process and reduce time-to-market. The microcontroller also supports in-system programming and in-application programming for easy firmware updates, facilitated by the built-in bootloader.

In summary, the STM32F100C8T6B microcontroller is an ideal choice for cost-sensitive applications that require a strong balance between performance and power consumption. Its extensive feature set and development support make it a flexible and accessible solution for a multitude of embedded system projects.
