Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Microchip Technology
Series PIC XLP 18K
Packaging Tube
Core Processor PIC
Core Size 8-Bit
Speed 48MHz
Connectivity I2C, SPI, UART/USART
Peripherals Brown-out Detect/Reset, HLVD, POR, PWM, WDT
Number of I/O 24
Program Memory Size 64KB (32K x 16)
Program Memory Type FLASH
EEPROM Size 1K x 8
RAM Size 3.8K x 8
Supply Voltage 2.3 V ~ 5.5 V
Data Converters A/D 19x10b
Oscillator Type Internal
Operating Temperature Range -40°C ~ 125°C (TA)
Package 28-VQFN Exposed Pad
Manufacturer Package 28-QFN (6x6)
Win Source Part Number 1238229-PIC18F26K22-E/ML
Manufacturer Homepage www.microchip.com
Popularity Medium
Supply and Demand Status Limited
Family Name PIC18F26K22
Introduction Date February 01, 2010
ECCN 3A991.a.2
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2023
Ultra Librarian 3D Model Ultra Librarian PIC18F26K22-E/ML CAD Model

Description

Microchip Technology's PIC18F26K22-E/ML Microcontroller

The PIC18F26K22-E/ML is a high-performance microcontroller unit (MCU) from Microchip Technology, designed to cater to a wide range of applications that require sophisticated control and connectivity features. This MCU is part of the PIC18F K22 family, which is well-known for its robust design, enhanced features, and flexibility in various complex embedded systems.

Key Features:

  • Core: The device is built on a high-performance PIC18 core with an operating speed of up to 64 MHz, providing a robust platform for applications that require fast processing and real-time responses.
  • Memory: It boasts a substantial program memory of 64 KB Flash, along with 3.8 KB of RAM and 1 KB of EEPROM, offering ample space for complex code and data storage.
  • I/O and Peripherals: The MCU comes with 25 I/O pins and a rich set of integrated peripherals, including two Enhanced Capture/Compare/PWM (ECCP) modules, four Serial Communication Interfaces (EUSART, SPI, I²C), and a 12-bit Analog-to-Digital Converter (ADC) with up to 28 channels, enabling versatile interfacing and sensor integration.
  • Power Management: With various power-managed modes, including Idle and Sleep, the PIC18F26K22-E/ML ensures efficient power consumption, making it suitable for battery-operated and power-sensitive applications.
  • NanoWatt XLP Technology: This technology offers extreme low-power consumption for applications that require energy efficiency, further extending battery life in portable devices.
  • Packaging: The MCU is available in a 28-pin QFN package, which is ideal for space-constrained applications without compromising on functionality.
  • Temperature Range: It operates within the extended temperature range of -40°C to +85°C, ensuring reliability and performance under variable environmental conditions.

Applications:

The versatility of the PIC18F26K22-E/ML makes it an excellent choice for a variety of applications, including industrial control systems, automotive electronics, home automation, consumer electronics, and medical devices. Its rich feature set and adaptability also make it a preferred option for prototyping and product development across multiple industries.

Summary:

In conclusion, the PIC18F26K22-E/ML from Microchip Technology is a feature-rich and versatile microcontroller that provides a balance of power, efficiency, and functionality, making it a go-to solution for designers and engineers looking to develop advanced and reliable embedded systems.
