Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Tray
Status Active
Core Processor ARM Cortex-M3
Part Core Size 32-Bit
Speed(Frequency) 120MHz
Number of I/O 114
Program Memory Size 768KB (768K x 8)
Program Memory Type FLASH
Data RAM Size 132K x 8
Supply Voltage - Operating 1.8 V to 3.6 V
Data Converters A/D 24x12b, D/A 2x12b
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 144-LQFP (20x20)
Win Source Part Number 212309-STM32F207ZFT6
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian STM32F207ZFT6 CAD Model

Description

STM32F207ZFT6 Microcontroller - STMicroelectronics

The STM32F207ZFT6 is a high-performance microcontroller from STMicroelectronics that targets a wide range of applications, including industrial control, medical equipment, and consumer electronics. This microcontroller is part of the STM32F2 series, which is renowned for its advanced architecture, enhanced peripherals, and increased performance.

At the heart of the STM32F207ZFT6 is an ARM Cortex-M3 processor core, which operates at a frequency of up to 120 MHz. This core provides the computational power necessary to handle complex tasks and algorithms. The microcontroller comes with a substantial 768 KB of Flash memory and 128 KB of RAM, ensuring ample space for application code and data storage.

The STM32F207ZFT6 is equipped with an extensive set of peripherals that enhance its connectivity and control capabilities. Notable features include a flexible static memory controller that supports Compact Flash, SRAM, PSRAM, NOR and NAND memories. It also provides a range of connectivity options such as USB OTG HS/FS, Ethernet, CAN, and several serial communication interfaces (UART, SPI, I2C, and more).

For applications requiring precise time control, the STM32F207ZFT6 offers multiple timers, including a PWM timer for motor control, a real-time clock, and watch-dog timers. Its 17-channel DMA controller streamlines data transfers, offloading the CPU and improving system efficiency.

The microcontroller's analog features are equally impressive, with 3x 12-bit ADCs with 24 channels and 2x 12-bit DACs, ensuring accurate analog signal management. Safety and reliability are addressed with features such as a memory protection unit (MPU), a fault-tolerant design, and a built-in temperature sensor.

The STM32F207ZFT6 is provided in an LQFP144 package, which allows for a compact design while still offering sufficient I/O pins for even the most I/O-intensive tasks. Developers can also take advantage of the extensive STM32 ecosystem, which includes development tools, software libraries, and community support, to expedite the design process and bring products to market faster.

In summary, the STM32F207ZFT6 is a versatile and powerful microcontroller that provides a balance of performance, memory, and peripherals, making it an ideal choice for demanding embedded system applications.
