Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Tray
Status Active
Core Processor ARM Cortex-M3
Part Core Size 32-Bit
Speed(Frequency) 32MHz
Number of I/O 37
Program Memory Size 64KB (64K x 8)
Program Memory Type FLASH
EEPROM Size 4K x 8
Data RAM Size 10K x 8
Supply Voltage - Operating 1.8 V to 3.6 V
Data Converters A/D 16x12b; D/A 2x12b
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 48-LQFP (7x7)
Win Source Part Number 089257-STM32L151C8T6
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name STM32L151C8
Introduction Date April 02, 2010
ECCN 3A991.a.2
Country of Origin China, Malaysia, Philippines, Taiwan
Halogen Free Compliant
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian STM32L151C8T6 CAD Model

Description

The STM32L151C8T6 is a cutting-edge microcontroller product from STMicroelectronics, designed for energy-conscious applications without compromising on performance. This microcontroller is based on the high-performance ARM Cortex-M3 32-bit RISC core, operating at a frequency of up to 32 MHz. The STM32L151C8T6 is part of the STM32L series focusing on ultra-low-power and efficiency, making it an ideal choice for battery-operated devices, energy harvesting applications, and smart sensors.

With a wide range of integrated features, the STM32L151C8T6 includes 64 KB of Flash memory, 10 KB of RAM, and 2 KB of EEPROM, providing ample storage for complex applications. Its robust peripheral set includes USB 2.0 full-speed interface, multiple timers, up to three USARTs, up to two SPIs, up to two I2Cs, an LCD interface, and a 12-bit ADC with 1.14 μs conversion time.

Security and system integrity are ensured with a hardware CRC calculation unit, while a true random number generator supports cryptographic applications. The device's low power consumption modes, such as sleep, stop, and standby, are enhanced by features like an ultra-low-power RTC, an independent watchdog, and a window watchdog timer.

The STM32L151C8T6 is also equipped with a comprehensive set of power-saving modes, allowing the design of low-voltage applications with excellent energy efficiency. Its dynamic voltage scaling optimizes the operating voltage to reduce the active power consumption, while a dedicated voltage regulator ensures stable operation during power fluctuations.

STMicroelectronics provides extensive support for the STM32L151C8T6 through its STM32Cube software ecosystem, which includes HAL libraries, middleware solutions, and a wide range of software examples. The microcontroller is also supported by a variety of development tools, including the STM32 Nucleo platform and the ST-LINK/V2 in-circuit debugger/programmer, simplifying the development process for engineers.

Whether you're developing low-power IoT devices, portable medical equipment, or energy-efficient consumer electronics, the STM32L151C8T6 offers a perfect blend of power efficiency, performance, and flexibility, making it a top choice for your next embedded project.
