Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type Smart ON/OFF Controller
Number of Voltages Monitored 1
Output Open Drain or Open Collector
Reset Active Low
Reset Timeout 240 ms Minimum
Voltage - Threshold 3.4V
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 12-TDFN (2x3)
Win Source Part Number 031341-STM6601DS2BDM6F
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian STM6601DS2BDM6F CAD Model

Description

STM6601DS2BDM6F - Smart Reset IC by STMicroelectronics

The STM6601DS2BDM6F is a sophisticated reset management IC designed by STMicroelectronics, tailored for modern digital devices that require reliable reset mechanisms. This integrated circuit is part of STMicroelectronics' Smart Reset™ family, which offers an innovative solution for managing the reset function in electronic products such as smartphones, tablets, and other portable consumer devices.

This smart reset IC is designed to enhance the user experience by providing a simple, yet effective way to reset a frozen device. It eliminates the need for complex key combinations or the removal of the battery, which can be inconvenient and sometimes impossible with today's sealed devices. Instead, the STM6601DS2BDM6F allows users to reset their device by simply pressing two external push-buttons simultaneously for a predefined duration, which can be adjusted according to the system requirements.

The STM6601DS2BDM6F features dual inputs that are monitored for a programmable time period, ranging from 5 seconds to 10 seconds, before asserting the reset signal. This programmable delay ensures that accidental resets are avoided, providing a more stable and user-friendly interface. The device operates over a wide supply voltage range, making it suitable for various applications and ensuring compatibility with different types of processors and digital cores.

In terms of packaging, the STM6601DS2BDM6F is offered in a compact, lead-free, halogen-free TSSOP8 package, which minimizes the footprint on the printed circuit board and aids in meeting environmental regulations. The compact form factor of this IC allows it to be easily integrated into space-constrained designs, making it an ideal choice for portable and wearable electronics.

Overall, the STM6601DS2BDM6F by STMicroelectronics represents a reliable and user-friendly solution for system reset management. Its smart functionality, programmable features, and compact design make it an essential component for designers looking to enhance the performance and safety of their digital devices.

For more detailed specifications and application guidelines, interested parties are encouraged to consult the datasheet and technical documentation available on the STMicroelectronics website.
