Products specifications

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 100V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 770mV @ 1A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 4μA @ 100V
Mounting SMD (SMT)
Case / Package SMB
Operating Temperature - Junction 175°C (Max)
Win Source Part Number 031498-STPS1H100U
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian STPS1H100U CAD Model

Description

STPS1H100U - STMicroelectronics Schottky Rectifier

The STPS1H100U is a high-efficiency, ultrafast Schottky rectifier designed and manufactured by STMicroelectronics. This power diode is specifically tailored for applications requiring low voltage drop and minimal power loss, making it an ideal choice for high-frequency inverters, freewheeling diodes, and polarity protection devices.

Key Features

  • Low Forward Voltage Drop: The STPS1H100U boasts a low forward voltage drop, which enhances the overall efficiency of the system it is integrated into by reducing thermal and conduction losses.
  • High Junction Temperature: With an operating junction temperature range of -40°C to +150°C, this rectifier is capable of handling high thermal stresses, ensuring reliability in a variety of challenging environments.
  • High Surge Current Capability: The device is designed to withstand high surge currents, which is crucial for applications prone to sudden overvoltage conditions.
  • Ultrafast Reverse Recovery Time: The fast switching characteristic minimizes energy loss during the transition from conducting to non-conducting state, which is particularly beneficial in high-frequency applications.

Applications

The STPS1H100U is versatile and can be used in a wide range of electronic circuits. Its robust design makes it suitable for:

  • Switching power supplies
  • Power management systems
  • DC-DC converters
  • Automotive applications
  • Reverse polarity protection

Package and Ratings

This Schottky rectifier comes in an SMB (DO-214AA) package, which is compact and suitable for automated assembly processes. It has a repetitive peak reverse voltage (V<sub>RRM) of 100V and an average forward current (I<sub>F(AV)) of 1A, making it a practical choice for medium-power applications.

With its combination of high efficiency, thermal resilience, and fast switching speed, the STPS1H100U from STMicroelectronics is an excellent choice for designers looking to optimize their power circuitry in both industrial and consumer electronic products.
