Products specifications

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr STMicroelectronics
Package Tape & Reel
Product Status Active
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 30 V
Current - Average Rectified (Io) 8A
Voltage - Forward (Vf) (Max) @ If 500 mV @ 8 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 1 mA @ 30 V
Mounting Type Surface Mount
Package / Case 8-PowerTDFN
Supplier Device Package PowerFlat™ (3.3x3.3)
Operating Temperature - Junction 150°C (Max)
Base Product Number STPS8
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 935617-STPS8L30DEE-TR
Ultra Librarian 3D Model Ultra Librarian STPS8L30DEE-TR CAD Model

Description

STPS8L30DEE-TR Power Schottky Rectifier

The STPS8L30DEE-TR is a robust power Schottky rectifier designed and manufactured by STMicroelectronics, a leader in semiconductor solutions. This component is engineered for high-performance applications that require low forward voltage drop and high surge current capability. The STPS8L30DEE-TR is a perfect choice for power supply designs, especially in compact and efficiency-oriented applications.

Key Features

  • Low Forward Voltage Drop: The device offers a low forward voltage drop, which enhances the efficiency of the system by reducing the power losses during conduction.
  • High Surge Current Capability: With its ability to handle high surge currents, this rectifier is well-suited for applications that experience frequent power surges or spikes.
  • Power Schottky Technology: Utilizing advanced Schottky barrier technology, the STPS8L30DEE-TR offers superior switching performance and improved thermal characteristics compared to traditional rectifiers.
  • High Junction Temperature: The component can operate at a high junction temperature, ensuring reliability and performance even under extreme conditions.
  • Low Leakage Current: The low leakage current of the device helps in reducing power consumption when in the off state, making it ideal for energy-saving applications.

Applications

  • Switching power supplies
  • Adapters and chargers
  • DC/DC converters
  • Free-wheeling diodes in power management
  • Automotive applications

The STPS8L30DEE-TR is housed in a surface-mount package, which makes it suitable for automated assembly processes and helps in saving board space. Its package is also RoHS compliant and designed for optimal thermal performance and mechanical robustness. With its impressive specifications and STMicroelectronics' reputation for quality, the STPS8L30DEE-TR is an excellent choice for designers looking to enhance the efficiency and reliability of their power management systems.

For detailed information, datasheets, and technical support, customers can visit the official STMicroelectronics website or contact authorized distributors. The STPS8L30DEE-TR is not only a testament to STMicroelectronics' commitment to innovation but also to its dedication to providing solutions that meet the evolving needs of the electronics industry.
