The STTH1002CB-TR is a state-of-the-art ultrafast recovery diode designed and manufactured by STMicroelectronics, a global leader in semiconductor solutions. This high-efficiency power diode is specifically engineered to meet the demanding requirements of high-frequency power switching applications and is ideal for use in power supplies, converters, and power factor correction circuits.
Key Features
- Voltage Rating: The diode has a repetitive peak reverse voltage (VRRM) of 200V, making it suitable for a wide range of applications in both industrial and consumer electronics.
- Current Capability: With an average forward current (IF(AV)) of 10A, the STTH1002CB-TR can handle significant power levels, providing reliable performance in high-power systems.
- Ultrafast Recovery Time: The diode boasts an extremely fast recovery time, typically less than 35ns, which minimizes power losses and improves overall efficiency, particularly in fast-switching circuits.
- Low Forward Voltage Drop: The low forward voltage drop (VF) ensures reduced conduction losses and enhances the overall thermal efficiency of the system it's integrated into.
- Robust Design: The device is housed in a TO-252 (DPAK) surface-mount package, which provides a compact footprint and excellent power dissipation characteristics.
- High Thermal Resistance: With a high junction to ambient thermal resistance, the STTH1002CB-TR ensures reliable operation even under high temperature environments, extending the lifespan of the product.
Applications
The versatility of the STTH1002CB-TR makes it an ideal choice for a variety of applications, including:
- Switch-mode power supplies (SMPS)
- Adapters and on-board DC/DC converters
- Freewheeling diodes in converters and motor control circuits
- Power factor correction (PFC) circuits
- Lighting applications
With its robust design, superior electrical characteristics, and compliance with RoHS and halogen-free standards, the STTH1002CB-TR from STMicroelectronics is an excellent choice for designers looking for a reliable and efficient ultrafast recovery diode.
